Operation
Figure 15 (Position load stroke)
When lifting the unit with the load, make absolutely sure that the support arm (3) does not move
beyond the maximum position (see Fig. 19), otherwise the clamping force will be too low and the load
could fall out. DANGER OF ACCIDENT!
This can be remedied by moving the gripping area inwards by moving the sliding gripper jaw (9) (see
Fig. 10 or 11).
