Safety
Positioning of the lifting eye (in the suspension) for the load
stroke.
Positioning of the lifting eye (in the suspension) for the empty
stroke (without load).
Each operator must have read and understood the operating
instructions (and all safety instructions).
The manual guiding of the device is only allowed at the red
handles.
OPTIONAL
Be sure that the fork sleeves are mechanically fixed (with locking
screw and safety chain or rope) to the lifting device.
OPERATING INFORMATIONS
Symbol
Meaning
Gripping range adjustments (in cm and inch)
53100439
7 / 27
29041063
50 mm
29041064
50 mm
29040665
Ø 30 mm
29040666
Ø 50 mm
29041049
Ø 80 mm
29040227
Ø 30 mm
29040226
Ø 50 mm
29040225
Ø 80 mm
29040223
Ø 50 mm
29040222
Ø 80 mm
Order-No.
Size
29041096
90x120 mm
