Product Overview
A
Robot (Top View)
A1
Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
Power Indicator Light
• White: Battery level ≥ 15%
• Red: Battery level < 15%
• Breathing: Charging or starting up
• Flashing red quickly: Error
• Flashing blue slowly: Waiting for
WiFi connection
• Flashing blue quickly: Connecting
• Steady blue: WiFi connected
Dock
• Press to start docking
Note:
Press any button to pause a running robot during
cleaning or docking.
A1-1—Vertical Bumper
A1-2— LiDAR Sensor
A1-3— Reactive Tech Obstacle Avoidance
Sensor
A1-4—Dock Locator
Robot (Bottom View)
A2
A2-1—Cliff Sensors
A2-2— Omnidirectional Wheel
A2-3— Carpet Sensor
A2-4— Side Brush
A2-5— Main Brush
A2-6— Main Brush Cover Latches
A2-7— Main Wheels
Robot (Top Cover Removed)
A3
A3-1—Top Cover
A3-2—Dustbin and Water Tank Combo
Unit
A3-3—Charging Contacts
A3-4—VibraRise Module
A3-5—Air Outlets
A3-6—Reset Button
A3-7—Bumper
VibraRise Module
A4
A4-1—Mop Cloth Attachment Slot
A4-2—Vibration Module
A4-3—VibraRise Mop Cloth Mount
A4-4—VibraRise Mop Cloth Mount Latches
VibraRise Mop Cloth
A5
A5-1—Hook and Loop Pads
Note:
Secure the mop cloth flat in place.
Power Cord
A6
Moisture-Proof Mat
A7
A7-1—Moisture-Proof Mat Adhesive Tape
Disposable Dust Bag
A8
005
Dustbin and Water Tank
A9
Combo Unit
A9-1—Dustbin and Water Tank Combo
Latches
A9-2— Dustbin Lid
A9-3— Cover Latch
A9-4— Water Tank Stopper
A9-5— Filter Handle
A9-6— Washable Filter
A9-7— Suction Inlet
A9-8— Dust Inlet
Auto-Empty Dock
A10
A10-1—Suction Inlet
A10-2— Charging Contacts
A10-3— Dock Location Beacon
A10-4—Dust Container Cover
A10-5—Status Indicator Light
• Steady white: Powered on and
robot not on the dock
• Flashing white slowly: Emptying
• Steady red: Dust bag is not in
place
• Off: Not Powered On/Charging
A10-6—Filter
A10-7— Dust Bag Slot
Auto-Empty Dock (Back View)
A11
A11-1—Power Cord Storage Slot
A11-2— Power Port
A11-3— Cord Outlets
Note:
Power cord can exit at either side.
