Starting Mopping
B4
Note:
To prevent excessive buildup of dirt on the mop
cloth, floors should be vacuumed at least three times
before the first mopping cycle.
B4-1—
Remove the dustbin and water tank
combo unit, open the water tank
stopper, and fill the water tank with
tap water before reinstalling the
stopper. Do not immerse the unit
into the water directly.
B4-2—
Dampen the mop cloth and wring it
until it stops dripping. Insert the
mop to the bottom of the mop cloth
attachment slot and stick it firmly.
B4-3—
Align the mop cloth mount with the
bottom of the combo unit and slide
it in until it clicks into place.
B4-4—
After the robot finishes cleaning and
returns to the dock, press two
latches of the mop cloth mount
inwards with both hands and pull
backwards to remove the mop cloth
mount.
Notes:
• To avoid deformation, only use cold water.
• Do not rinse or immerse the dustbin and water tank
combo unit with water.
• To prevent damage, do not use any disinfectant
and only use cleaning solution recommended by
Roborock.
• Dampen the mop cloth and wring it until it stops
dripping. Install the mop onto the mop cloth mount
and stick it flat in place. After mopping, empty the
water tank of unused water immediately.
• All combo units are subject to water-based tests
before leaving the factory. It is normal that a small
amount of water remains in the unit.
Connecting to the App
1. Download the App
Search for "Roborock" in the App Store or
Google Play or scan the QR code to
download and install the app.
2. Reset WiFi
Press and hold
and
simultaneously
until you hear the "Entering network
configuration mode" voice message. The
reset is complete when the power indicator
light flashes blue slowly. The robot will then
wait for a connection.
Note:
If you cannot connect to the robot due to your
router configuration, a forgotten password, or any
other reason, reset the WiFi and add your robot as a
new device.
3. Add Device
Open the Roborock app, tap the "Add
Device" or "+" button and add your device
following the in-app guide.
Notes:
• The actual process may vary due to ongoing app
updates. Follow the guide provided in the app.
• Only 2.4 GHz WiFi is supported.
• If the robot stays in network setup for more than 5
minutes, the setup will be stopped automatically.
007
Instructions for Use
Turning On/Off
Press and hold
to turn on the robot. The
power indicator light will come on, and the
robot will wait for orders.
Press and hold
to turn off the robot and
complete the cleaning cycle.
Note: The robot cannot be turned off when it is being
charged.
Starting Cleaning
Press
to start cleaning. The robot will
plan its cleaning route and in each room, it
firstly draws out edges and then fills the
room in a zigzag pattern. In so doing, the
robot cleans all rooms one by one,
thoroughly and efficiently.
Notes:
• Before cleaning, tidy cords (including the power cord
of the dock) and valuables from the floor. Loose
items may be dragged by the robot, resulting in the
disconnection of electrical appliances or damage of
cords and property.
• Before starting each cleaning task, make sure that the
mop cloth have been properly installed.
• To make sure the robot returns to the dock
automatically, start the robot from the dock and do
not move the dock during cleaning.
• Cleaning cannot start if the battery level is too low.
Allow the robot to charge before starting a cleanup.
• If the battery runs low during a cleaning cycle, the
robot will automatically return to the dock. After
charging, the robot will resume where it left off.
• The robot will retract mop cloth mount to clean the
carpet. You can also set the carpet as a no-go zone in
the app to avoid it.
