C1-6—Turn over the robot and press the
two latches inwards to remove the
main brush cover.
C1-7—
Pull out the main brush and remove
the main brush bearing on the left as
shown in the picture. Remove any
entangled hair or dirt at both ends
of the main brush. Then, reinstall the
main brush bearing.
C1-8—
Reinstall the main brush and main
brush cover, and press the cover
securely.
Notes:
• It is recommended to wipe the main brush with a wet
cloth. If the main brush is soaked, air-dry it away from
direct sunlight.
• Do not use corrosive cleaning fluid or disinfectant to
clean the main brush.
Side Brush
C2
* Clean monthly and replace every 3-6 months.
1. Unscrew the side brush screw. Remove
and clean the side brush.
2. Then, reinstall the brush and tighten the
screw.
Omnidirectional Wheel
C3
* Clean as required.
C3-1—
Use a tool, such as a small
screwdriver, to pry out the axle and
take out the wheel.
Note:
The omnidirectional wheel bracket cannot be removed.
C3-2—
Rinse the wheel and the axle with
water to remove any hair and dirt.
Air-dry, reinstall, and press the wheel
and axle back in place.
Main Wheels
C4
* Clean as required.
Clean the main wheels with a soft, dry cloth.
Dustbin and Water Tank
C5
Combo Unit
* Clean as required.
C5-1— Open the top cover of the robot and
take out the unit.
C5-2— Open the dustbin lid and remove the
washable filter, then empty and clean
the dustbin.
C5-3— Open the water tank stopper, and
empty the tank of unused water.
C5-4— Reinstall the unit in the robot.
Note: After mopping, empty the water tank, wash the
mop cloth, and air-dry them to prevent odors.
Washable Filter
C6
* Clean every 2 weeks and replace every 6-12 months.
C6-1— Open the dustbin lid and take out
the filter.
C6-2— Rinse the filter repeatedly and tap it
to remove as much dirt as possible.
Note:
Do not touch the surface of the filter with hands,
brushes, or sharp objects to avoid potential damage.
C6-3— Allow at least 24 hours for the filter to
dry thoroughly before reinstalling it.
VibraRise Mop Cloth
C7
* Clean after each use and replace every 3-6 months.
C7-1— Hold the mop cloth mount by both
ends to remove it.
009
C7-2— Remove the mop cloth from the
mount.
C7-3— Wash the mop cloth and then air-dry it.
Robot Sensors
C8
* Clean as required.
Use a soft, dry cloth to wipe and clean all
sensors, including:
C8-1—Dock Locator
C8-2— Reactive Tech Obstacle Avoidance
Sensor
C8-3— Carpet Sensor
C8-4— Cliff Sensors
Charging Contacts
C9
* Clean as required.
Use a soft, dry cloth to wipe the charging
contacts on the robot and the dock.
Moving the Dock
C10
To move the dock, grip from the bottom of
the dock as shown in the picture.
Auto-Empty Dock
C11
* Replace dust bag immediately when the bag is full to
ensure emptying performance.
C11-1— Open the dock cover, lift the dust
bag out of the dustbin and discard it.
C11-2—Clean the filter with a dry cloth.
C11-3— Install a new dust bag in place and
close the dock cover.
Note:
Make sure the dust bag is installed in place along the
slot to prevent dust leakage and damage the dock.
