SIWAREX
9.6 Reading/writing data records
1. Click the button . By doing so, you send all the data records from the MFCT to the WP321
module. You can only operate the button if the PC values and the SIWAREX values are
different from each other.
2. Click the button . By doing so, you read all the data records from the WP321 module into
the MFCT.
By right-clicking in the "Parameters" area, you open a pop-up menu. In it, you can, for
example, run the following commands for the opened data record:
• Reading from the WP321 module into the PC value
• Writing the PC value into the WP321 module
Monitoring
In the "Monitoring" area, you can monitor all the process value data records with read access.
50
MultiFieldbus Configuration Tool (MFCT)
Configuration Manual, 03/2024, A5E53511456-AA
