16
CONTROL UNIT
Art. 54250 / 54255
Vedi note a pag. 19
See notes at p. 19
Voir remarques à p. 19
COLLEGAMENTO A SCHEDA SENSORIA ART. 53500 / 53501
CONNECTION TO SENSITIVE BOARD ART. 53500 / 53501
RACCORDEMENT A CARTE SENSORIELLE ART. 53500 / 53501
MANIGLIONE
HANDLE BAR
BARRE
Vedi note a pag. 19
See notes at p. 19
Voir remarques à p. 19
COLLEGAMENTO AD INDICATORI LUMINOSI
CONNECTION TO LIGHT INDICATORS
RACCORDEMENT AUX VOYANTS LUMINEUX
NC 1
21
NO 1
22
23
COM 1
NC 2
24
25
NO 2
26
COM 2
Art. 53500 / 53501
-V
+V
N
L
ALIMENTATORE
POWER SUPPLY
ALIMENTATEUR
GND
APERT
Art.
55010
Art.
55030
CONTROL UNIT
Art. 54250 / 54255
+12 V OUT
11
13
3
4
5
6
7
8
