Spécifications
Orientation
Sealed DLP™ core
Inputs
Input resolutions
Picture-in-picture
CLO (constant light output)
ScenergiX
Image processing
Keystone correction
Integrated web server
Software tools
Control
Network connection
Dimensions (WxLxH)
Weight
Cooling liquid hose length
Power requirements
Ambient temperature
Operational humidity
Power consumption
3D systems
Safety class
Certifications
*Note
134 R5906150FR /04
Tilt 45° up and 30° downwards | Rotation – 20 degrees / +90 degrees
(=Portrait)
Standard
Slot 1 :Dual HDBt; HDMI 2.0 (HDCP 2.2); DP 1.2 (HDCP 1.3); Quad 3G/
12G SDI / BarcoLink | Slot 2: Quad DP1.2
From NTSC up to 4K (4,096 x 2,160) 120 Hz
refresh rates:
24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2160)
Two sources simultaneously
Standard
Horizontal and vertical edge blending
Embedded warp & blend engine
Yes
Yes
Projector Toolset
XLR wired + IR, RS232, Wifi (opt), GSM (opt)
10/100 base-T, RJ-45 connection, Wifi (optional)
Projector: 744 x 1,445 x 706 mm / 29.3 x 56.9 x 27.8 inches (with feet, no
lens) | Two chillers, each with the following dimensions: 701 x 701 x 800
mm / 27.6 x 27.6 x 31.5 inches
Projector: 235kg (~520lb) / Chillers: ~115kg (~250lb) per chiller (two
chillers needed)
2.5-5-10m (8.2-16.4-32.8ft)
Projector: 200-240/346-415V 50-60Hz 16A 3W+N+PE (Y connection) /
Power cord size range: 4 sq mm to 6 sq mm, 10AWG to 8AWG /Circuit
breaker range: 25A to 40A | 200-240V 3W+PE 28A 50-60Hz (/\-
connection) / Power cord size: 6 sq mm, 8AWG / Circuit breaker: 40A
Chillers: 230/400V 3W+N+PE 16A, 2.5 sq mm (Y connection) or 208V /
3W+PE (/\- connection) / Max. 16A per phase
10-35°C (95°F) Max. (projector and chillers)
5-80% (non condens)
Projector @ full laser power: 6.7 kW (2D or Polarization 3D) / 3.6 kW
(Barco Laser3D - 6P)
Chillers @ full laser power: 3.0 kW (2D or Polarization 3D) / 2.5 kW (Barco
Laser3D - 6P)
Color3D (Barco Laser3D): Native 6-primary color-3D system. Only
requires color filter glasses / Active glasses systems / Polarization
recuperation systems
Class 1, RG3
CE; ETL/UL/FCC
*Less than 20% decrease during a runtime of 20,000 hrs
XDL
