V1.0
4. Dashes indicating the field strength will appear on the LCD, increasing
from one (weak) to four (strong). A buzzer will rise in frequency as the EF
increases (Fig. 8).
CARE & MAINTENANCE
1. Maintain the tool with care. A tool in good condition is efficient, easier
to control and will have fewer problems.
2. Inspect the tool components periodically. Repair or replace damaged
or worn components. Only use identical replacement parts when
servicing.
3. Only use accessories intended for use with this tool.
4. Maintain the tool's labels and name plates. These carry important
information. If unreadable or missing, contact Princess Auto Ltd. for
replacements.
WARNING! Only qualified service personnel should repair the tool.
An improperly repaired tool may present a hazard to the user
and/or others.

FUSE REPLACEMENT

1. Switch the dial to OFF position and remove the test leads from the
input terminals.
2. Loosen the both screws (Fig. 10-1) on the
rear cover (Fig. 10-2), then remove the
rear cover to replace the fuses (Fig. 10-3).
Replace each fuse with one of the same
type.
10A Input Jack (D): Fuse 10A/250V
Ø5x20 mm ceramic tube.
VΩmA Input Jack (F): Fuse 0.2A/250V Ø5x20 mm ceramic tube.
3. Press the rear cover back into place and secure with both screws.

BATTERY REPLACEMENT

Replace the battery when the battery indicator (
readings.
1. Switch the dial to OFF position and remove the test leads from the
input terminals.
Visit www.princessauto.com for more information
25 pc Soldering Master Kit
) appears to avoid false
8868259
Fig. 10
13
