PARTS LIST – MOTOR AND GEARBOX
# DESCRIPTION
8.1 Circlip 19-Hole
8.2 Button
8.3 Spring
8.4 Arbor
8.5 Screw M8×8
8.6 Arbor Spindle
8.7 Oil Seal
32
MAGNETIC DRILL
QTY 8.8
1 8.9
1 8.1
1 8.11
1 8.12 Dishing Washer
2 8.13 Washer
1 8.14 Brass Washer
2 8.15 Big Gear
