Normal Operation
2.1.4.3
Current Step Number
Press formulas usually include multiple steps, as when pressure is gradually increased. The step
number increments at the beginning of each step.
2.1.4.4
Desired Pressure in Bar
This field displays the programmed membrane pressure for this step, as measured in bar.
1 bar = 0.9872 atmosphere = 1 x 10
2.1.4.5
Minimum Time
This timer begins counting down when the programmed membrane pressure is achieved. The step
ends when this timer reaches 0 unless the maximum press time is achieved first.
2.1.4.6
Maximum Press Time
This timer begins counting down when membrane pressurization begins. The step ends when this
timer expires, even if the desired pressure has not been achieved.
2.1.4.7
Current Pressure in Bar
This field displays the current membrane pressure.
2.1.4.8
Animation and Graphing Region
This display region shows an animation of the press in operation or a line graph of the membrane
pressure.
•
Press
to display a graphic representation of the major press components. Each compo-
nent is outlined when the component is stationary, or solid blue when the component is mov-
ing under power.
•
Press
to display a graph of membrane pressure. The graph always begins when the oper-
ator presses
presses
). The graph displays a maximum of two minutes before older values scroll off
the left side of the window. A new pressure reading is plotted about every half second.
2.1.4.9
Message Region
During normal operation, text messages such as machine states and error conditions are displayed
in this area.
16
and ends when the graph is replaced by the animation (when the operator
BNP1VO01.C08 0000579995 A.2 B.2 A.6 7/13/23, 7:23 AM Released
BNP1VO01.C09 0000579994 A.3 B.2 A.6 7/13/23, 9:25 AM Released
5
N/m
2
= 14.504 PSI
BNP1VO01.C10 0000579993 A.2 B.2 A.6 7/13/23, 7:23 AM Released
BNP1VO01.C11 0000579992 A.2 B.2 A.6 7/13/23, 7:23 AM Released
BNP1VO01.C12 0000579991 A.2 B.2 A.6 7/13/23, 7:23 AM Released
BNP1VO01.C13 0000579990 A.2 B.2 A.6 7/13/23, 7:23 AM Released
BNP1VO01.C14 0000579989 A.2 B.2 A.6 7/13/23, 7:23 AM Released
Pellerin Milnor Corporation
