ELSG
ELSGF
EBSG
1.1.2.4 Signal Cancel Switch
The signal cancel switch is a momentary push-button switch which makes an input to the micro-
processor controller to end the operator signal.
Display or Action
SHSC
1.1.2.5 Start Switch
When power is enabled through the master switch and all safety conditions are met for the ma-
chine to run, this momentary push-button switch allows machine operation. Pressing this switch
closes contacts in relay CRS+, which remain closed as long as the three-wire circuit is intact.
Display or Action
SHS+
SHS+R
1.1.2.6 Run/Program Keyswitch
The run/program keyswitch helps prevent unauthorized programming by removing a microproc-
essor input required to modify the contents of the memory on the microprocessor controller.
Display or Action
Pellerin Milnor Corporation
This notation in wiring diagrams refers to the operator signal
lamp on the main switch panel.
This notation in wiring diagrams refers to the operator signal
beacon mounted on top of the control box.
This notation in wiring diagrams refers to the operator signal
horn.
Explanation
This symbol represents the signal cancel switch in this manual.
This notation in wiring diagrams refers to the signal cancel
switch.
Explanation
This symbol represents the start switch in this manual.
This notation in wiring diagrams refers to the start switch.
This notation in wiring diagrams refers to the remote start
switch, which serves the same purpose as SHS+. Remote start
switches may be mounted on the side of the machine opposite the
main switch panel, and/or on auxiliary switch panels at other loca-
tions on the machine.
Explanation
This symbol represents the run/program keyswitch in the Run
position, as during normal operation. The key can only be re-
moved from the switch in this position.
BNPUUO01.C07 0000579461 B.2 A.6 7/26/24, 3:17 PM Released
BNPUUO01.C08 0000579460 B.2 A.6 7/26/24, 3:46 PM Released
BNPUUO01.C09 0000579459 B.2 A.6 7/26/24, 3:50 PM Released
Controls
7
