11 - TROUBLE SHOOTING

PROBLEM
Machine switch off
No water in boiler
No unit delivery
Steam fails to come out of
the nozzle
Too much water in the boiler
Signs of water leakage on
bench
Wet coffee dregs
Coffee dispensing too slow
Coffee dispensing too fast
Coffee delivered cold

12 - MACHINE DISMANTLING

For a correct disposal of the machine, please follow the instructions
contained on the last pages of the manual.
CAUSE
1. Mains switch off
2. Machine switch off
3. Incorrect electrical mains connection
1. Mains tap closed
2. Clogged pump fi lter
3. Motor driven pump not in operation
1. mains tap closed
2. motor driven pump out of order
3. clogged gigleur
4. burnt control box fuse
5. unit solenoid valve out of order
6. unit switch out of order
1. too much water in boiler
2. damaged resistance
3. clogged sprayer element
4. resistance saver engaged
1. the motor driven pump remains enga-
ged
2. perforated exchanger
3. automatic charge solenoid valve bloc-
ked
1. dirty drain tray
2. drainage pipe clogged or detached
3. other leakage
1. Grinding regulated too fi ne
2. Unit still cold
3. Solenoid valve fails to discharge
1. grinding element set too fi ne
2. dirty fi lter-holder
3. clogged unit
4. gigleur or solenoid valve partially clog-
ged
1. grinder is regulated too large
1. Lime scale present on the exchangers
or the resistances
2. oxidized pressure switch contacts
3. defective electrical connection
4. partially burnt out resistance
REMEDY
1. position the machine switch to position ON
2. position the machine switch to position 1
3. contact specialized personnel in order to
check the connection
1. open the mains tap
2. replace the fi lter
3. contact specialized personnel
1. open the mains tap
2. contact specialized personnel
3. contact specialized personnel
4. contact specialized personnel
5. contact specialized personnel
6. contact specialized personnel
1. see specifi c problem
2. contact specialized personnel
3. clean the sprayer element
4. reinsert the resistance
1. contact specialized personnel
2. contact specialized personnel
3. contact specialized personnel
1. clean the try
2. replace the drainage pipe
3. contact specialized personnel
1. Adjust grinding value
2. wait for the machine to reach the cor-
rect temperature
3. contact specialized personnel
1. Adjust the grinder
2. replace the fi lter and undertake more
frequent fi lter-holder cleaning
3. contact specialized personnel
4. contact specialized personnel
1. regulate the grinding
1. contact specialized personnel
2. contact specialized personnel
3. contact specialized personnel
4. replace the resistance element
