2.6 Foreseeable misuse
Misuse ( ) with corresponding intended use ( ):
 Use of diesel fuel and instead of test oil.
 Only use Divinol CAF test oil (manufacturer number:
2928V3).
---
 Failure to observe maintenance intervals.
 Perform maintenance according to the specified
maintenance intervals.
---
 Use of manually created test sequences with incor‐
rect parameters.
 Only use the test sequences specified by Bosch.
---
 Setting incorrect calibration values.
 Enter correct calibration values.
---
 Use outside the allowed ambient conditions.
 Use the DCI 700 only under the allowed ambient
conditions.
---
 Testing of damaged injectors or injectors that have
not been cleaned.
 Prior to clamping, test and clean the injectors as
specified.
---
2.7 Warranty and liability
The use of unapproved hardware and software will re‐
sult in a modification of our products and thus to the
exclusion of any liability or warranty, even if such hard‐
ware and software have been removed or deleted again
in the interim.
No modifications may be carried out on our products.
Our products may only be used with genuine accesso‐
ries and genuine spare parts. Otherwise, all warranty
claims will be rendered null and void.
This product may only be operated using operating sys‐
tems approved by Bosch. If the product is operated
with an operating system other than the one approved,
then the warranty obligation expires in accordance with
our terms of delivery. Furthermore, no liability can be
assumed for damages and consequential damages that
have their cause in the use of an operating system that
has not been released.
---
2.8 Protective clothing and equipment
• Safety goggles
• Safety shoes
• Protective gloves
When working on the DCI 700, always wear your per‐
sonal protective clothing and equipment.
---
3. Product description
--- 3.1 Scope of delivery
Denomination
DCI 700
1x parts set with monitor, mounting and key‐
board shelf
Robert Bosch GmbH
Denomination
1x cable gland for cable diameter 13 – 18 mm
1x thread reducer for cable gland
1x parts set with 4 injector chamber devices
1x parts set for Bosch commercial vehicle
common rail injectors
1x parts set for Bosch commercial vehicle
common rail injectors 4.2
4x pressure sensors (SST)
1x holding device for hand scanner
4x knurled nut D7
4x O-ring insert D7 without O-rings
40x O-ring 12 x 2 mm for O-ring inserts D7
and D9
40x O-ring 7 x 4 mm for O-ring insert D7
40x O-ring 9 x 3 mm for O-ring insert D9
4x hose assembly for the injected-fuel quanti‐
ty
4x hose assembly for the test oil return
4x return adapter for Bosch CRI
4x return adapter hose assembly for Bosch
CRI 2.18 and CRI 2.20
4x return adapter hose assembly for Bosch
CRI 3
4x adapter nut M14 x 1.5
2x storage tray
1x drain hose for emptying the heat exchanger 1 680 712 392
1x square box wrench
4x adapter cable for Bosch CRI 1, CRI 2x and
CRI 3x
4x adapter cable for Bosch CRI 3-25 and
CRI 3-27
1x protective hose yellow (1000 mm)
1x recovery USB stick
1x original instructions
1x original instructions
1x installation instructions
---
1)
Only with product variant DCI 700 USA/Canada
(0 683 725 003)
The order numbers are not part numbers. The or‐
der numbers are used to identify the items inclu‐
ded in the scope of delivery. Components that
can be ordered are identified as spare parts or
wearing parts.
---
3.2 Optional accessories
• 1 687 010 607: accessory set for testing Bosch com‐
mercial vehicle common rail injectors (CRIN 1x,
CRIN 2x, CRIN 3x)
Order number
• 1 687 010 608: accessory set for testing Bosch com‐
-
mercial vehicle common rail injectors (CRIN 4.2)
1 685 200 173
DCI 700 | 5 | en
Order number
1 683 391 591
1 680 365 013
1 687 016 196
1 687 010 607
1)
1 687 010 608
1)
1 687 231 266
1)
1) 1 685 200 178
1 683 373 087
1 680 109 141
1 680 210 123
1 680 210 124
1 680 210 132
1 687 410 056
1 680 712 382
1 687 016 215
1 683 351 066
1 680 712 315
1 683 345 066
1 685 520 631
1 681 982 011
1 684 465 900
1 684 465 895
-
1 688 400 654
1 689 989 473
1) 1 689 989 563
1 689 978 630
1)
1 689 989 473 | 2023-09-24
