Start-up
14 Operating Manual Biowelder
5.3

Installation

The Biowelder TC is portable and can be used in any location. Use a secure
®
and horizontal base for the installation. Make sure to place the machine in a
way that the access to the on/off switch and the emergency off button is
well accessible!
Connect the power cord with safety earthing to the device socket and
switch it on. The power supply must be according to the technical data.
After a brief start-up section the device is ready to operate.
The raiser is responsible for the safety of the system and its integration .
5.4

Login

The device is set upon delivery so that a user with the name "Supervisor"
from the "Supervisor" user group or the name "Example" from the
"Operator" user group can login without a password. In this case,
the instructions needed to execute initialisation are displayed on the
touch screen.
An automatic login can be activated. See Chapter 6.2.9 User management
5.5

Maintenance

There is no spare part list for Biowelder
Sartorius recommends to have a yearly intervention and maintenance
executed by your local Sartorius Service representative that includes
temperature sensor validation. Please contact your local Service
representative from Sartorius to establish a maintenance contract.
This information has to be confirmed with the OK button on the screen.
Contact your Sartorius Stedim Biotech Service Representative, if
maintenance is needed.
5.6

Entering settings

Different settings such as the following can be entered from a Supervisor
of the "Supervisor" user group via the menu: language, date, time and
type of tube.
Read the corresponding Chapter 6 .2 Touch screen
5.7

Initializing axes

After the device starts up, an initialisation must be executed. Follow the
instructions on the touch screen.
The tube holder and the blade are removed from the device .
The user then closes the cover .
Total Containment
®
TC available for the customer.
®
