Program stage
The current temperature
in the chamber
During the course of the program, in place of the START fi eld, the STOP fi eld is displayed, which allows the user to stop the process at any time. In
the upper left corner of the screen, the names of the individual stages of the program are displayed consecutively, e.g. chamber lock, heating of the
working chamber.
WARNING! After the process, the chamber, tray and load are hot. Be especially careful and use protective gloves to remove the
load or wait until it cools down. In the 134C FAST program, instruments are hot and wet after sterilization.
Test programs
The devices are equipped with special test programs to verify the correct operation of the sterilizer.
Maxima Turbo
Process temperature
Number of pre-vacuums
Sterilization time
Drying time
Total process time
Temperature of the selected process
STOP button
If the process was successful, the display alternately shows information screens about
the end of the process and the sterility of the load and about the possibility of opening the
chamber of the device. By pressing the FINISH fi eld, you go to the welcome screen.
Bowie & Dick / Helix
134°C (273°F)
3
3.5 min
3 min
15 min
By pressing the Test fi eld you go to the test programs menu. From this level, we can choose
between the Vacuum test and Helix / B&D test programs. You select the appropriate pro-
gram by pressing the required fi eld on the display.
Approximate time to the
end of the process
Current pressure in the
chamber
Vacuum test
-
1
-
-
16 min
