PARTS LIST
RCLP155B
KEY PART
NO.
NO.
DESCRIPTION
1
098511-116
Upper Shell, Model RCLP155B
2
100647-01
Screw, #10-16 x 1/2"
3
098512-35
Combustion Chamber Kit
4
099138-01
Nozzle
5
099133-01
Ignitor
6
M11084-38
Screw, #8-18 x 3/8"
7
099334-01
Fuel Tube Kit
8
097806-02
Ignitor Cable
9
M51108-01
Heat Shield
10
M51153-01
Fan
11
103404-01
Motor
12
097776-01
Universal Bushing
13
078978-01
Sleeve Cap
14
M51572-02
Male Connector
15
099132-01
Solenoid Valve
16
097966-04AA Base
17
M51605-02
DSI Control
18
M12461-7
Screw, #6-32 x 1"
19
099432-01
Hex Nut, #6-32
20
M11084-27
Screw, #10-16 x 1/2"
21
M50104-05
Shorty Bushing
22
M50104-01
Shorty Bushing
23
101732-01
Thermal Limit Switch
24
097968-05
Screw, #4-40 x 1/2"
25
097384-04
Hex Nut, #4-40 Captive Washer
26
098511-131
Lower Shell, Model RCLP155B
27
097965-02AA Side Cover
28
098226-01
On/Off Switch
103909
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 10 of this manual.
OWNER'S MANUAL
KEY PART
QTY.
NO.
NO.
29
101480-03
1
30
098276-01
8
31
M51104-01
1
32
M11084-29
1
33
101206-01
1
34
098138-02
2
35
M11143-1
1
36
098219-17
1
37
M50631
1
38
NTC-4C
1
39
099157-01
1
40
099125-01
1
41
M12461-25
1
42
M9900-170
1
43
M11271-8
1
44
101480-02
1
1
PARTS AVAILABLE-NOT SHOWN
2
097941-23
2
079663-01
10
079663-02
1
099164-04
1
100176-02
1
100865-03
2
LPA3070
2
LPA1010
1
LPA2100
1
LPA4020
1
HA1210
9
DESCRIPTION
High Temperature Wire Assembly
Plug 1/8 NPTF Hex
Handle
Screw, #10-16 x 3/4"
Fan Guard
Motor & Relay Support Bracket Assy.
Strain Relief Bushing
Power Cord
Rubber Bumper
Lock Nut
Break Mandrell Rivet, 3/16"
Terminal Board
Screw, #10-32 x 1/4"
Wire Assembly
Clip Nut
High Temperature Wire Assembly
Tradename Decal, Model RCLP155B
LP Warning Decal (English)
LP Warning Decal (French)
Wiring Decal
Warning Decal
Operation Decal
Regulator & Hose Assembly
10' Hose Assembly
Regulator
Fuel Gas Connector
Thermostat
QTY.
1
1
1
2
1
1
1
1
2
2
1
1
2
1
8
1
2
1
1
1
1
1
1
1
1
1
