SPECIFICATIONS
Input Rating (Btu/Hr)
Fuel
Fuel Consumption
Liters (Gallons)/Hour 6 (1.6)
Kg (Pounds)/Hour
Supply Pressure To Regulator
Minimum (for purposes
of input adjustment)
Maximum
Regulator Outlet Pressure
(Factory Preset)
Manifold Pressure
Hot Air Output
(CFM Approx)
Motor
Electric Input
Amperage
Ignition
Ignitor Gap
Weight
Heater
Shipping
Size - L x W x H cm (in) 92.7 x 36.8 x 50.8 (36
Blue
Insulated
Connector
Power Cord
120 VAC
103909
150,000
Propane Vapor Only
26.4 (7.0)
69 (kPa) 10 psi
Tank Pressure
31.8 cm (12.5 in) WC
24.9 cm (9.8 in) WC
15.6 (550)
3,430 RPM, 1/8 HP
120 V/60 Hz
2.2
Direct Spark, Interrupted Type
3.3/3.8 mm (.13/.15 in)
11 kg (24 lb)
16 kg (35 lb)
1
/
x 14
4
Electrical Connection Diagram
Thermal
Switch
Blue
Blue
Black
On/Off
Switch
Black
OWNER'S MANUAL
WIRING
DIAGRAMS
Black
Blue
T T
1
/
x 20)
2
Line
Blue
Solenoid
Valve
Green
Safety
Control
G
V VR ACR AC
Black
White
Fuse (If Equipped)
T
White
7
Electrical Ladder Diagram
Green
Thermal
Switch
Blue
Solenoid
Valve
Position of
Leads May
Safety
Vary
Control
G V VR ACR AC
Green
Blue
Blue
Black
Fuse *
Black
* If Equipped
Orange
Ignitor
Position of
Leads May
Vary
Motor
Black
White
Green
Green
White
Ignitor
Orange
White
White
Motor
Green or
Green/Yellow
Neutral
