LANCE HANGERS AND ADJUSTABLE KIT CONTINUED
4
Once both hangers are in place, use two people to lift the fixture to the
installed handing hardware . Be sure to hang from the center of the lance
hanger to ensure a balanced fixture . If using the Adjustable Hanger Kit,
hook the Gripple hooks on each lance hanger . Adjust the height on each
end until level by sliding the Gripple hook up or down along the cable . To
slide down, squeeze and hold the release mechanism on the sides of the
hook .
RACKS WITH TRAY AND VAS
Please refer to the illustration to find the correct hanger configuration for your
specific application.
ABS Tray
VAS
VAS
~6" [15 cm]
ABS Tray with VAS
VAS
VAS
~6" [15 cm]
10
ABS Tray
~4" [10 cm]
ABS Tray without VAS
~8" [20 cm]
~4" [10 cm]
VAS Hanger
Medium
~6" [15 cm]
VAS Hanger
VAS Hanger
Short
LONG
VAS Hinge Brace
