Electrical installation to standard, in compliance with
legislation in force in the country of installation.
•
Electrical installation according to safety standards and
legislation in force.
•
The charging station must only be connected to a power
supply system with neutral conductor connected to the
earth.
•
The charging station must be protected by a type A
residual current device.
•
The power line must be protected by an adequate circuit
breaker with C curve.
•
The connections compartment should only be opened by
qualified staff.
•
Use the device exclusively for applications compliant with
its intended use.
•
Do not use private generators as a charging power source.
The charging station should be installed in a location that
meets the following requirements:
•
Protected from direct sunlight.
•
Sufficiently ventilated.
•
Far from sources of heat.
•
Ambient temperature between -25°C and +50°C.
•
Altitude above sea level up to 2000m.
•
Protected from rainwater, running water and other liquids.
•
Easily accessible.
•
Maintain a distance of at least 500 mm from other devices
or objects.
Do not install the charging station in:
•
Locations with constant dust production (both conductive
and non-conductive).
•
Locations with presence of corrosive vapours, acids or salts.
•
Locations with flammable substances.
•
Locations at risk of explosion.
4.1 Wall mounting
Carefully unpack the charging station, checking all parts are
intact. Keep the original packaging if it may be sent for any
repairs. The content of the package is outlined in Fig. C.
The device must be assembled in the vertical position at a
height of approximately 150cm (from the lower edge to the
floor). The assembly wall must be flat and stable.
Remove the two screws (M3) on the front of the equipment
(Fig. D-1), open it and remove the internal screw (M6).
Remove the bracket from the rear of the equipment (Fig. D-2).
Fasten the bracket to the wall using the 2 screws supplied (Fig.
D-3).
Fasten the cable winder to the wall using the 3 screws supplied
(Fig. D-3).
Position the device over the bracket and slide it top to bottom
parallel to the wall until all the fittings are hooked to the
respective slots. Check correct positioning, checking it is
parallel to the wall. Try to distance it from the wall to check its
correct hooking to the shelves. Fasten the equipment with the
specific screw (M6), which was previously removed (Fig. D-4).
4.2 Electrical connection
The electrical connection should be installed:
•
In compliance with national legislation.
•
Only by qualified operators.
•
After fastening the device to the wall.
The charging station must have a dedicated power line,
protected by an adequate circuit breaker switch with C curve
and a type A residual current device (See 7.1).
For electrical connection installation:
•
Disconnect the power line via the circuit breaker switch
and residual current device.
•
Insert the cable using the cable gland on the lower side.
There is also a corrugated tube which can be used to
protect the cable.
•
Remove the sheath from the cable, strip the cores of the
conductors and crimp adequate eyelets with the hole for
the M6 screw (Fig. E-1).
•
Fasten the cable to the specific single-phase (Fig. E-2) or
three-phase (Fig. E-3) terminal board.
•
Close the front of the equipment (Fig. D-4) with the two M3
screws.
