5.2.2 Types of lighting
The Remote Control – Modulator – Transformer – Led Projector unit enables you to create different lighting settings inside the pool with two
operation options:
Set colour : Selection of a set colour among twelve possibilities.
Automatic sequence of colours: Selection of eight colour sequence programmes. Each programme is defined by the lighting time of each colour
and the transition time from one colour to another according to the following table:
SEQUENCE
1 Red
2 Cyan
Emerald
3 Green
4
Red
5 Red Magenta
6 Red
Pale
7
Violet
8 Red
6. MAINTENANCE:
This lamp does not require any type of maintenance work. If you notice that the lamp is not working properly, please contact our customer
attention service.
THIS PRODUCT DOES NOT CONTAIN ANY ELEMENTS THAT CAN BE HANDLED, DISMANTLED OR REPLACED BY THE USER. IT IS
FORBIDDEN TO ACCESS INSIDE THE PRODUCT, OTHERWISE THE GUARANTEE OF THE PRODUCT WILL BECOME INVALID.
7. CHANGE OF LAMP:
First, you have to extract the projector up to the edge of the swimming pool (Fig. 1), you must turn the 2 screws (no 1) to the position OPEN
until the wedge of fixation gives up (Fig. 6 and 7).
To remove the lamp, unscrew the 6 nuts (no. 10) which secure the decorative ring (no. 2) to the base of the floodlamp (no. 9) (Fig. 10).
Remove the lamp (no. 6) from the inside of the base of the floodlamp (Fig. 9) and disconnect the two terminals, loosening the two screws which
secure them to the lamp (Fig. 10).
Change the lamp and assemble the Floodlamp, in the opposite order described in point 4 of assembly, taking special care to:
Connect the cable terminals to the lamp, using the 2 screws supplied with the lamp (Fig. 12).
•
Fully centre the 110x11 O-ring (no. 8) in its seat.
•
Firmly tighten the nuts.
•
Attention:
Before any handling ensure that there is NO voltage supplied to the floodlamp.
•
The new lamp should have the same characteristics as that supplied with the floodlamp, of led PAR56, 12 V.
•
In order to ensure full watertightness, clean the seat of the O-ring (no. 6) for the lamp or replace the O-ring if you observe any notches or
•
permanent damage.
THE HOLES AT THE BACK OF THE LAMP (FIG. 11) SHOULD BE LEFT FREE WHEN ASSEMBLING THE PROJECTOR, SO THAT WATER

8. SAFETY WARNINGS:

The persons who are in charge of assembly should have the required qualifications for this type of work.
•
If the end cable of this light fitting is damaged, it should only be replaced by the manufacturer, its technical service or by a similarly qualified
•
person, to avoid any danger.
Avoid making contact with the electric voltage.
•
Comply with the current standards regarding accident prevention.
•
In this regard, the IEC 364-7-702 standards must be observed. WIRING IN BUILDINGS. SPECIAL WIRING. SWIMMING POOLS.
•
Any operation related to the maintenance or replacement of parts should be performed with the floodlamp disconnected from the electric
•
power system.
Do not handle with wet feet.
•
The lamp is designed TO BE USED ONLY SUBMERGED IN WATER and TO OPERATE ONLY WITH A SAFETY TRANSFORMER.
•
The manufacturer is not responsible in any circumstances for assembly, installation or start-up of any electric components which have been
•
inserted or handled at locations other than its own premises.
The projector is equipped with a 2x1.5 section cable according to the power of the lamp supplied. If the lamp is changed, the cable section
•
should be recalculated and changed if necessary.
1 Red
2 Green
3 Blue
4 Yellow
5 Cyan
6 Purple
Green Blue
Purple Yellow
Cyan Sky-blue
green
Orange Green Orange
Blue Magenta
Orange Green Cyan
Purple Cyan Yellow
Green Blue Yellow
CAN FLOW INSIDE FOR OPTIMUM PERFORMANCE OF THE LAMP.
7 Sky-blue
8 Pale Violet
9 Orange
10 Magenta
11 Emerald green
12 White
Blue Sky-blue Cyan
Blue Magenta
White Yellow Cyan
Pale
Cyan Purple
Violet
A T T E N T I O N
4
Emerald
green
Purple
Sky-blue Orange Magenta
Emerald
White
green
