FUSE REPLACEMENT

1. Engage the parking brake (13, Fig. E).
2. Turn the ignition key (24, Fig. D) to OFF position and remove it.
3. Remove the transparent cover of the fuse box (25 or 34, Fig. D) and replace the relevant fuse among the following:
Fuse box (25, Fig. D)
1. Free fuse holder (10 A)
2. Free fuse holder (7.5 A)
3. Parking brake warning buzzer and water-in-fuel sensor fuse (10 A)
4. Dashboard fuse (7.5 A)
5. Reverse gear warning buzzer, cameras, start safety relay, and hopper door fuse (10 A)
6. Skirt solenoid valve fuse (10 A)
7. Broom rotation fuse (10 A)
8. Relay board fuse (10 A)
9. Lifted hopper warning light/windscreen washer fuse (7.5 A)
10. Dust control system water pump fuse (15 A)
11. Climate control system fuse (15 A)
12. Hydraulic system oil cooling fan fuse (20 A)
Fuse box (34, Fig. D)
13. High beam fuse (15 A)
14. Running light fuse (7.5 A)
15. Hazard warning light and horn fuse (10 A)
16. Low beam fuse (15 A)
17. Running light fuse (7.5 A)
18. Glow plug control unit fuse (7.5 A)
19. Turn signal fuse (7.5 A)
20. Flashing light fuse (7.5 A)
21. Fuel solenoid valve fuse (engine off) (10 A)
22. Brake light fuse (10 A)
23. Windscreen wiper fuse (7.5 A)
24. Climate control system blower fuse (20 A)
4. Install the transparent cover of the fuse box (25 or 34, Fig. D).
