Nobles Speedshine 1700LS Manuel De L'opérateur page 27

REF PART # DESCRIPTION
1 200823 GRIP, HANDLE TUBE
2 608385 HANDLE, GREEN
(SINGLE SPD & HD MODELS)
608404 HANDLE, GREEN
(DUAL SPD MODELS)
3 608464 LABEL, SPEEDSHINE 1200
6084630 LABEL, SPEEDSHINE 1600
608398 LABEL, SPEEDSHINE 2000
4 230856 PIN, LOCK RELEASE
5 230857 SOCKET, LOCK
6 140401 SPRING, LOCK BUTTON
7 230855 BUTTON, LOCK RELEASE
8 140900 SCREW, #10–24X3/4
9 230854 BRACKET, SWITCH
10 140519 NUT, #10–24
11 140539 NUT, #6–32
DSWITCH
12 605407
13 140032 WASHER, #6 FLAT
14 140829 SCREW, #6–32X1
15 140324 CLAMP, CABLE 5/16 ID BLK NYLON
(SINGLE SPD & HD MODELS)
140328 CLAMP, CABLE 3/8ID BLK NYLON
(DUAL SPD MODEL)
16 612763 PLATE, HANDLE REAR
17 613286 LABEL, WARNING
18 140197 SCREW, 10–24X3/8 TRSPHL SEM
19 140823 SCREW, 10–24X5/8 PHL
20 230853 HANDLE, TUBE
DBREAKER, CIRCUIT 15A (120V)
21 605197
22 28990 NUT, 8–32 NYLOCK
∇ ASSEMBLY / CONJUNTO
INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
Y
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS PARA
MANTENER EN EXISTENCIA
Speedshinet 1700LS/1700HD/1700DS/2000LS/2000HD/2000DS (09–02)
All manuals and user guides at all-guides.com
HANDLE GROUP
GRUPO DEL ASA
QTY.
2
1
1
1
1
1
1
1
1
1
3
1
8
2
1
1
2
1
1
1
1
2
2
1
1
2
REF PART # DESCRIPTION
23 6010.16 SCREW, 8–32X1
24 600987 SPRING
25 100355 SLEEVE, LOCKING
26 140259 SCREW, HEX .25–20X.62
DGRIP, CORD (120V)
27 602849
DCORD, 14/3X50' YELLOW (120V)
28 602747
29 230852 PLATE, BACKING
30 140147 SLEEVE, .25X.44X.20
31 140146 SLEEVE, .25X.50X.19
32 140604 PIN, GROOVE 1/4X3/4
33 611141 LATCH, HANDLE
34 200821 GRIP, LATCH
35 602750 HOOK, CORD
36 140052 WASHER, 1/4 EXT
37 140864 SCREW, 1/4–20X3/4
38 230859 CHANNEL, LATCH HANDLE
39 140402 SPRING, HANDLE LATCH
40 140881 SCREW, 1/4–20X1
41 140524 NUT, 1/4–20 KEP
42 130204 CORD, 14/3X57" BLACK
(SINGLE SPD & HD MODELS)
130203 CORD, 14/4X57" BLACK
(DUAL SPD MODEL)
43 130141 BUSHING, STRAIN–RELIEF
DBELT CLIP, STRAIN–RELIEF
44 130176
(OPTIONAL)
45 140148 SLEEVE, .625DX1.4L
46 3148.816 WASHER, FLAT
47 140024 WASHER, LOCK
48 140235 SCREW, 1/2–13X2 HXHDCP
49 130726 SWITCH, TOGGLE
(DUAL SPD MODELS)
50 130990 BOOT, RUBBER SWITCH BLACK
(DUAL SPD MODELS)
51 120675 LABEL, OPERATION
(DUAL SPD MODELS)
PARTS LIST
LISTA DE PIEZAS
QTY.
1
1
1
1
1
1
3
4
2
1
1
1
2
5
5
1
1
1
1
1
1
1
1
2
2
2
2
1
1
1
27
