Endress+Hauser Proline Promag 55 Instructions Condensées page 18

Montage
ASME
Diamètre Palier de
nominal pression
[inch] [lbs]
1½" Class 300
2" Class 150
2" Class 300
3" Class 150
3" Class 300
4" Class 150
4" Class 300
6" Class 150
6" Class 300
8" Class 150
10" Class 150
12" Class 150
14" Class 150
16" Class 150
18" Class 150
20" Class 150
24" Class 150
Couples de serrage Promag S pour AS 2129, Table E
Diamètre
AS 2129
nominal
Palier de
[mm] pression
25 Table E
50 Table E
80 Table E
100 Table E
150 Table E
200 Table E
250 Table E
300 Table E
350 Table E
400 Table E
450 Table E
500 Table E
600 Table E
18
Vis
Caoutchouc naturel
4 × ¾" –
4 × 5/8" –
8 × 5/8" –
4 × 5/8" 15
8 × ¾" –
8 × 5/8" 11
8 × ¾" –
8 × ¾" 24
12 × ¾" –
8 × ¾" 38
12 × 7/8" 42
12 × 7/8" 58
12 × 1" 77
16 × 1" 75
16 × 1 ¹⁄₈" 108
20 × 1 ¹⁄₈" 105
20 × 1¼" 161
Vis
4 × M 12
4 × M 16
4 × M 16
8 × M 16
8 × M 20
8 × M 20
12 × M 20
12 × M 24
12 × M 24
12 × M 24
16 × M 24
16 × M 24
16 × M 30
Couple de serrage max. [lbf · ft]
Promag S
Polyuréthane PTFE
11 25
16 35
8 17
32 58
19 35
23 41
30 49
44 78
38 54
59 105
55 100
76 131
117 192
111 181
173 274
160 252
226 352
Couple de serrage max. [Nm]
PTFE
21
42
–
–
–
–
–
–
–
–
–
–
–
Proline Promag 55
PFA Ebonite
23 –
32 26
16 13
49 44
31 28
37 31
44 43
63 58
49 52
80 79
– 75
– 98
– 100
– 94
– 150
– 135
– 198
Ebonite
–
32
16
13
22
36
37
57
85
99
96
115
199
