Overload Clutch
If the tool insert becomes caught or jammed,
the drive to the drill spindle is interrupted.
Because of the forces that occur, always
hold the power tool firmly with both hands
and provide for a secure stance.
If the power tool jams, switch the machine
off and loosen the tool insert. When switch-
ing the power tool on with the drilling tool
jammed, high reaction torques can occur.
Temperature Control Indicator
The red LED of the temperature control indicator
13 signals that the battery or the electronics of
the power tool (when the battery is inserted) are
not within the optimum temperature range. In
this case, the power tool will not operate at full
capacity.
Temperature control of the battery:
– The red LED 13 lights up continuously after in-
serting the battery into the charger: The bat-
tery is not within the charging temperature
range between 0 °C and 45 °C and cannot be
charged.
– The red LED 13 flashes when pushing button
15 or pressing the On/Off switch 7 (when the
battery is inserted): The battery is not within
the temperature range for operation of
– 10 °C to +60 °C.
– For battery temperatures over 70 °C, the
power tool switches off until the battery is in
the optimal temperature range again.
Temperature control of the power tool
electronics:
– The red LED 13 lights up continuously when
pressing the On/Off switch 7: The tempera-
ture of the machine's electronics is below
5 °C or above 75 °C.
– At a temperature above 90 °C, the electronics
of the power tool switch off until the temper-
ature is within the allowable temperature
range again.
Bosch Power Tools
All manuals and user guides at all-guides.com

Working Instructions

Vibration Damper
The integrated vibration damper reduces occur-
ring vibrations.
The soft grip handle increases the safety against
slipping off and thus provides for a better grip
and handling of the power tool.
Inserting Screwdriver Bits (see figure J)
To work with screwdriver bits, a universal bit
holder 26 with SDS-plus shank (accessory) is re-
quired.
Clean the shank end of the adapter shank and
apply a light coat of grease.
Insert the universal bit holder with a turning
motion into the tool holder until it automatically
locks.
Check the locking effect by pulling the universal
bit holder.
Insert a screwdriver bit into the universal bit
holder. Use only screwdriver bits that match the
screw head.
To remove the universal bit holder, pull the lock-
ing sleeve 4 toward the rear and remove the uni-
versal bit holder 26 out of the tool holder.
Recommendations for Optimal Handling
of the Battery
Protect the battery against moisture and water.
Store the battery only within a temperature
range between 0 °C and 45 °C. As an example,
do not leave the battery in the car in summer.
Occasionally clean the battery venting slots using
a soft, clean and dry brush.
A significantly reduced working period after
charging indicates that the battery is used and
must be replaced.
Observe the notes for disposal.
Apply the power tool to the screw/nut only
when it is switched off. Rotating tool inserts
can slip off.
