English
1 General
Installation and service by qualified personnel
only.
1.1 Fields of applications
Series IPL (Inline) and DPL (Dual) glanded pumps
are used for circulating duties in mechanical build-
ing services to serve:
• Central hot water heating systems
• Chilled and condenser water systems
• Closed industrial circulating systems
• Heat transfer systems.

1.2.2 Technical data

Motor speeds: IPL, DPL
Connection sizes DN: IPL
DPL
Permissible temperature min./max.
Maximum ambient temperature
Maximum working pressure
Insulation class
Enclosure rating
Pipe and gauge connections
Permissible fluids
Electrical wiring connections
Thermal resistor sensor
Variable speed control
●
Standard design
Special design or additional equipment at extra cost
Alternative application of standard design (no additional costs)
When ordering spare parts, all data of pump and
motor name plate must be stated.
Permissible fluids:
When using water/glycol mixtures of a mixing
ratio up to 40% glycol (or fluids of viscosities
other than water) it will be necessary to correct
the hydraulic pump data according to the higher
viscosity, depending on the mixing ratio and
the fluid temperature. Only approved makes of
additives with corrosion inhibitors in strict com-
pliance with manufacturers` instructions must be
used.
The fluid must be free of sediments.
2 Safety rules
These instructions contain basic rules on safety
aspects which must be strictly adhered to for
installation and operation. It is therefore impera-
tive for Installers and Operators to study these
10
All manuals and user guides at all-guides.com
1.2.1 Serial codes
IPL/-DPL (3-7,5 kW)
IPL
DPL
50
/170
-7,5
/2
2900, 1450 1/min
32 – 100
32 – 100
–10°C to +120°C
40°C
10 bar
F
IP 55
Flanges PN 16 to DIN EN 1092-2
1
with gauge tappings / " BSP
8
Heating water to VDI 2035
Chilled/condenser water
Water/Glycol-mixtures up to 40 % glycol content
Heat transfer oil
Other media on request
3 400 V, 50 Hz
~
3 230 V, 50 Hz: up to 3 kW
~
3 230 V, 50 Hz:4 kW and above
~
3 440 - 480V 60Hz
~
Pol change multi-speed motors
Automatic control gear (Wilo-CR-System)

1.2 Product information

IPL = Inline-pump
DPL= Double-pump
Pump connection size [mm]
Nominal impeller diameter [mm]
Rated motor power kW
2-pole motor
instructions prior to installation and commission-
ing.
Not only the safety references under this main
heading need attention but also those added
and specifically marked under the ensuing head-
ers.
2.1 Symbols marking safety reference in these
instructions
Safety precautions in these operating instructions
which, if not followed, could cause personal injury
are indicated by the symbol:
Safety precautions warning of danger due to
electricity are indicated by the symbol:
The following symbol is used to indicate that by
ignoring the relevant safety instructions, damage
could be caused to the pump/machinery and its
functions:
ATTENTION!
●
●
●
●
●
Wilo AG 10/2005
