RCM BIT 391CB/3 Utilisation Et Entretien page 54

EN
OPERATIONS TO
PERFORM WEEKLY
11.1.d - Cleaning the clean water
filter (Fig. 17)
- Unscrew the transparent filter cover (1)
and remove the filter (2).
- Clean the filter (2) in running water. If it is
blocked, replace it.
- Replace all the components in reverse
order.
OPERATIONS TO
PERFORM WHEN
NECESSARY
11.1.e - Replacing the brush
(Fig. 18)
It becomes necessary to replace the brush
when it is worn with bristles shorter than 2
cm or it must be replaced according to the
type of floor to wash; to replace it, proceed
as follows:
- Plug in the electrical cord (only for ver-
sion C).
- Lift the machine up slightly at the front,
levering the grips on the handle.
- Press the button (3) to enable the rota-
tion of the brush, then press levers (4)
and release them; the brush (5) is discon-
nected.
- Replace the brush and then rest the
brush holder flange (6) on the brush (5)
and press the levers (4) listening for the
coupling "CLICK" of the brush on the
flange.
- Set the button (3) to the "0" position.
2
4
EN-22
1
Fig. 17
4
3
6
5
Fig. 18
