MP85A(DP) FASTpress, MP85A(DP)−S EASYswitch
2

Connecting the sensors

2 sensors (transducers) can be independently connected to screw terminals 5
and 6 (e.g. channel 1 displacement and channel 2 force). HBM transducer
cables or other shielded, low capacitance measurement cables should be
used. The shield of the transducer cable must be connected as closely as
possible (< 5 cm) to the flat plug (4.8 mm).
Screw terminals 5 and 6
for transducer connection
SENSOR X
1
SENSOR Y
1
SG and inductive full bridges,
piezoresistive transducers
wh
Measurement signal (+)
bk
Bridge excitation
voltage (−)
rd
Measurement signal (−)
Bridge excitation
bu
voltage (+)
gn
Sense lead (+)
gy
Sense lead (−)
ye
Cable shield
Potentiometric transducer
(half bridge function)
2
1
3
Cable color code:
wh= white; bk= black; bu= blue; rd= red; ye = yellow; gn= green; gy= gray
To connect other sensors,refer to the Online help or the operating instructions.
A2073-5.0 en/de/fr
MP85A(-S)
8
8
Flat plug for the transducer cable shield
1
2
6
4
5
3
Hsg.
Measurement
1
signal (+)
2
Bridge excitation
voltage (−)
4
Bridge excitation
voltage (+)
Cable shield
Hsg.
Sense lead (+)
5
3
Sense lead (−)
MP85ADP(-S)
SG and inductive half bridges
wh Measurement
signal (+)
bk
Bridge excitation
voltage (−)
Bridge excitation
bu
voltage (+)
gn
Sense lead (+)
gy
Sense lead (−)
ye
Cable shield
LVDT transducer
Measurement
signal (+)
Bridge excitation
voltage (−)
Bridge excitation
voltage (+)
Measurement
signal (−)
Sense lead (+)
Sense lead (−)
7
1
2
4
5
3
Hsg.
1
2
4
6
Cable shield
Hsg.
5
3
