ASTRA TEE® Operator's Manual
APPENDIX C: SITE REQUIREMENTS & SPECIFICATIONS
Actual Size :
Width: 12.0" (30.5 cm)
Depth: 14.0" (35.6 cm)
Height: 65.0" (165 cm)
Weight: 73 lbs. (33.1 kg)
Minimum Clearances Required:
Front: 12.0" (30.5 cm)
Left: 12.0" (30.5 cm)
Right: 12.0" (30.5 cm)
Top: 4.0" (10.2 cm)
Electrical Requirements:
Service: 115 VAC (±10%) 60Hz, 15A Hospital Grade GFCI receptacle within 8 ft. (2.4 m) is required
l
Fuse: 2.0 Amp Slo Blo, 250V, 5 mm X 20 mm
l
Category II installation
l
Water Supply Requirements:
A permanent cold-water supply connection within 8 ft. (2.4 m) is required.
l
Incoming water pressure: 30 - 50psi (207 – 345kPa)
l
Recommended minimum flow rate: 1 gpm (3.8 lpm) at 30 psi (207 kPa)
l
Temperature: Cold water supply 50 - 80°F (10 - 27°C)
l
Drain Requirements:
A drain connection is required using supplied tubing; the device may drain directly into an existing sink,
l
dishwasher drain standpipe, or connected permanently to existing plumbing drain.
Environmental Requirements:
Indoor use only
l
Altitude up to 6560 ft. (2000m)
l
Operating Temperature: 65 - 80°F (18 - 27°C)
l
Pollution degree 2 environment
l
Room Humidity 20 - 80% RH non-condensing
l
When disposing of this equipment and accessories, follow all applicable national, state and local regulations and
l
guidelines.
Long Term Storage Recommendations:
Indoor environment (protected from outdoor elements, i.e. rain)
l
Temperature exposure greater than 32°F to less than 120°F
l
Humidity exposure should not be greater than 80%
l
M0068_F 30
