The electronics of the machine offers the opportunity to exploit a
range of functions that allow to optimize the heating and DHW per-
formance, described in detail in the specific chapters:
- programming the parameters
- setting the thermoregulation.
Designed to be connected to the FAMILY REmote Control (acces-
sory).
2.1 Safety devices
The FAMILY CONDENS KIS E boiler is equipped with the following
safety devices:
Safety valve that intervenes in the event of excessive hydraulic pres-
sure (max 3 bar).
Water circuit diagnosis which safeguards the boiler in the event of
insufficient circulation or lack of water. The electronics of the boiler,
by comparing the temperature read by the outlet and return sensors
(circulation analysis) and the rise rate of the output temperature (no
water analysis) ensures the safety lockout of the appliance.
Flue gas probe: this intervenes (putting the boiler in safety stop
mode) if the temperature of the combustion products exceeds the
maximum operating temperature of the discharge pipes.
Flue gas safety evacuation system incorporated in the pneumatic
operation of the gas valve subject to the premix burner The gas valve
is opened based on the quantity of air pushed by the fan.
This implies that, if the flue gases exhaust circuit is blocked, the air
flow is cancelled and the valve does not have the ability to open.
Furthermore, the float present in the siphon prevents any passage of
the flue gases from the condensation discharge.
Condensate discharge obstruction safety device that via a con-
densate level sensor blocks the boiler if the level of condensate in the
heat exchanger exceeds the limit allowed
Over-temperature safety device on both the delivery and return
lines, with dual probe (limit temperature 95°C).
Fan safety that, through a Hall effect revolution counter, constantly
monitors the rotation speed of the fan.
The intervention of the safety devices indicates a boiler mal-
function, therefore immediately contact the Riello Technical
Assistance Service It is therefore possible to try and put the
boiler back in service after a short wait (see chapter on "First
commissioning").
The boiler must not be put in service, even temporarily, with
non-operating or tampered safety devices.
Replacement of safety devices must be performed by the Ri-
ello Technical Assistance Service, by exclusively using original
manufacturer components and referring to the spare parts list
accompanying the boiler. After carrying out the repair, perform
an ignition test.
2.2 Circulator setting
Circulator residual discharge head
The boilers is equipped with an already hydraulically and electrically
connected circulator, whose useful available performance is indicated
in the graph (fig. 1-2-3-4).
The circulator is factory set with discharge head of 6 meters.
The boiler is equipped with an anti-blocking system which starts
up an operation cycle after every 24 hours of stop, with the mode
selector in any position.
The "anti-locking" function is only activated when the boiler is
electrically powered.
It is strictly forbidden to operate the circulator without water.
Where there is the need to use a different curve, the desired level can
be selected on the circulator.
The main characteristics and how to set the desired operation are
described below.
User interface
The user interface is made up of a button (A), a two-coloured red/
green LED (B) and four yellow LEDs (C) arranged in a row (fig. 5). The
user interface allows to view the operating performance (operating
status and alarm status) and set the operating mode of the circulator.
The performance, indicated by LEDs (B) and (C) are always visible
during the normal operation of the circulator, while the settings are
made by pressing button (A).
Indication of the operating status
When the circulator is operating, LED (B) is green. The four yellow
LEDs (C) indicate the consumption of electric power (P1) as shown
in the following table
LED status
CIRCULATOR
Green LED on +
Minimum operation
1 yellow LED on
Green LED on + Minimum-medium
2 yellow LEDs on
Green LED on + Medium-maximum
3 yellow LEDs on
Green LED on +
Maximum operation
4 yellow LEDs on
(*) For the output (P1) absorbed by the circulator, refer to that indicat-
ed in the "Technical Data" table.
Indication of the alarm status
If the circulator has detected one or more alarms the bi-colour LED
(B) is red. The four yellow LEDs (C) indicate the type of alarm as
shown in the following table.
ALARM
LED status
description
Red LED
on + The crankshaft
1 Yellow LED is blocked
on (LED 5)
Red LED
on +
Low input voltage
1 yellow LED
on (LED 4)
Red LED
Electrical power
on +
supply failure or
1 yellow LED
circulator fault
on (LED 3)
If there are multiple alarms, the circulator displays the highest
priority alarm only.
Display of the active settings
With the circulator powered, the active configuration of the circulator
can be viewed by briefly pressing the button (A). The LEDs indicate
the active settings.
No change to the configuration of the circulator can be made at this
stage. Two seconds after of pressing the button (A), the user inter-
face returns to the normal display of the operating status.
Key lock function
The key lock function is designed to prevent an accidental change of
settings or misuse of the circulator.
When the lock function is activated, the prolonged pressing of button
(A) is inhibited. This prevents the user from entering the setting sec-
tion of the circulator operating mode.
The enabling/disabling of the key lock function is made by pressing
button (A) for more than 10 seconds. During this step, all LEDs (C)
flashes for 1 second (fig.6).
Status Consumption in %
of P1 MAX (*)
0÷25
25÷50
operation
50÷75
operation
100
Status Possible
CIRCULATOR REMEDY
Start attempt Wait or
every 1.5 unblock the
seconds crankshaft
Warning only.
The circulator Check the
continues to input voltage
operate
Check the
electrical
The circulator
supply or
has stopped
replace the
circulator
