NOTE:
• Always switch the battery off when the pulling device is
not being used. In this way, you can guarantee that no
current will flow and the risk of self discharge of the
battery is as small as possible.
WARNING!
• Always switch the battery off before you remove the
pulling device.

7.5. Charge status display for the battery

The battery has an integrated charge status display. This
is fitted on the front side of the battery. Using this display
you can check the charge status of the battery quickly
and easily.
• Press the ON/OFF button (A) quickly
• 4 green LED (B) means 100% charged, 3 LED= 75%, 2
LED= 50%, 1 LED=20%
• The display will go back off after approximately 10
seconds.
Empulse StreetJet Rev.A

7.6. Detaching the battery

• The battery can be removed for charging or as
protection against theft.
• In order to prevent unauthorised removal of the battery,
the battery is fixed to the battery bracket with a lock.
• The battery can be removed as follows:
○ Switch the battery off (see "Switching the battery on
and off").
○ Open the lock using the key. To do this insert the
key into the lock and then rotate it 90° anti-clockwise
until it reaches the stop. Keep it in this position.
○ The battery can now be tipped to the right (in the
direction of travel). To do this hold the battery at the
top and push it to the side.
• To fit, insert the lower part of the battery into the floor
plate of the battery bracket, then push the upper part of
the battery gently against the battery bracket and push
to the left (in the direction of travel) until the battery
clicks into the battery bracket.
NOTE:
• The pulling device is delivered with two identical keys.
Always store the keys separately and make a note of
the key number.
51
