4.3) Programming the "Photo-test" mode
To activate the "Photo-test" mode, make the connections described in
paragraph 2.3.3 "Notes on Connections" (see Figs. 6a – 6b), and not
the connections shown in Figs. 5a – 5b).
Table "A4" Activating "Photo-test"
1. Press and hold down the PROG button
2. When the OK Led remains permanently on;
press STEP-BY-STEP; the courtesy light switches on
3. Release the PROG button
Table "A5" Deactivating "Photo-test"
1. Press and hold down the PROG button
2. When the OK Led remains permanently on, press STEP-BY-STEP;
the courtesy light switches off
3. Release the PROG button
Check whether the "Photo-test" mode is activated or deactivated:
power the control unit and check how long the OK Led flashes,

5) Testing:

!
The automation system must be tested by qualified and
expert staff who must establish what tests to perform
according to the relative risk.
Testing is the most important part of the whole installation phase. Each
single component, e.g. motors, photocells and other safety devices, the
radio receiver and the emergency stop can require a specific test phase;
please follow the procedures shown in the respective instructions
manuals.
To test the control unit, carry out the following procedure (the sequence
refers to the control unit of the SP6000 with pre-set functions).
• After powering the control unit, check that the OK Led flashes at 1
second intervals. If this does not occur, turn power off immediately and
check the fuse.
• Check that all the safety devices of the unit are in proper working order
(emergency stop, photocells, pneumatic edges, etc.). Whenever a
device cuts in, the OK Led flashes rapidly twice to signal that the event
has been acquired.
• Now it is possible to carry out a complete cycle of the actuator. Press
the "Step-by-step" button and check that the door stops automatically
at the travel stop. Press the "Step-by-step" button again and check
8
• if it flashes rapidly for 2 seconds, "Photo-test" is deactivated;
• if it flashes rapidly for 4 seconds, "Photo-test" is activated.
that the door stops automatically at the opposite travel stop. Carry out
several manoeuvres in order to evaluate any defects of installation or
adjustment of the gear motor travel stops, as well as the presence of
any friction points. While the closing manoeuvre is being performed,
the board automatically memorises the time taken. After a complete
cycle of manoeuvres (open and close touching both travel stops) the
control unit decelerates movement during the final 3 seconds of the
closing phase.
• Now check the safety devices cut in correctly. The ones connected to
the "Photo" input have no effect during the opening manoeuvre but
they will invert movement during the closing manoeuvre. The devices
connected to the "Stop" input work during both the opening and
closing manoeuvres and stop movement in each case.
In the closing manoeuvre, the control unit reduces speed and noise
during the final phase. The point at which the reduction in speed takes
place is automatically calculated according to the duration of the previous
manoeuvres; for this reason it is necessary to carry out a few complete
manoeuvres until the speed reduction point is established (at least ten
manoeuvres should be carried out to establish the exact point in which
speed reduces).
