Graco TABLE2BOOST Instructions page 11

Tray Cover
30 Attach tray cover by pushing it down on the tray.
31 To remove pull up on the back of the tray.
To Secure Your Child
-
See images 32 34
35 Use slide adjuster at shoulder and waist for
further adjustment. Repeat on other side.
36 When changing harness strap slots, MAKE SURE
harness straps are going through same slots in
seat pad and seat back.
37 The harness straps must go into the slot that is
even with or slightly above the shoulders. Avoid
twisting straps.
Adjusting Height
38 WARNING: DO NOT adjust the height of the
product with the child in it.
To adjust height, squeeze buttons on the back of
both legs and lower or raise seat.
39 There are 4 height positions.
Recline
40 WARNING: DO NOT adjust the seat recline with
the child in it.
Squeeze handle on back of seat and push down or
pull up to adjust.
41
There are 3 recline positions.
Attaching infant/toddler feeding
booster seat to chair
42 Turn infant/toddler feeding booster seat over.
Open clear compartment on bottom of infant
feeding booster seat.
43 Pull straps out of compartment as shown.
44 Insert two rear straps into slots in infant/toddler
feeding booster seat as shown.
45 Place infant/toddler feeding booster seat on
a chair with no armrests and that has a back,
ensuring that the straps are hanging freely.
Make sure that there are no extra seat-pads or
cushions on the chair that you are using with the
infant/toddler feeding booster seat.
46 Wrap top straps around back of chair and secure
clip. Tighten by pulling on the adjustment strap.
47 Wrap bottom straps around base of chair and
secure clip under the chair. Tighten by pulling on
the loose strap.
CHECK to make sure infant/toddler feed-ing
booster seat is securely attached by moving from
side to side.
48
See image.
49 Ensure the infant/toddler feeding booster seat is
attached correctly by pulling up on it.
To remove infant/toddler feeding
booster seat from chair
50
Unfasten clips on bottom of seat.
51 Unfasten clips from back of seat.
52 Remove infant/toddler feeding booster seat from
seat.
53 Fold and store straps in compartment on bottom
of infant/toddler feeding booster seat as shown.
54 Close compartment door.
MAKE SURE the compartment door is closed
before attaching infant/toddler booster seat back
onto the highchair frame.
