Instructions
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE USE AND KEEP THEM
FOR FUTURE REFERENCE. YOUR CHILD'S SAFETY MAY BE AFFECTED IF YOU DO NOT
FOLLOW THESE INSTRUCTIONS.
Assembling Highchair
1 To set up, squeeze buttons on either side of
highchair legs and push front legs forward as
shown.
2 Attach legrest by snapping it onto center bar as
shown.
3 Rotate legrest down to secure. Be sure the bar is
securely attached into the legrest as shown.
4 Insert footrest into slots as shown.
5 Rotate footrest down to secure. You may need
to adjust position of footrest once your child is
seated in chair.
6 See image.
Infant/Toddler Feeding Booster Seat
Assembly
7 While pulling up on handle on seat back, insert
seat back, into the slots on the seat base as
shown.
8 Release handle on back and allow rods on side of
seat back to insert into one of the sets of holes in
the seat base.
Rods should be inserted into same slots on each
side of the seat.
09 Flip seat over.
Insert pins into seat base and seat back as shown.
Seat Pad
10 Insert webbing through opening in seat back as
shown.
11 Attach seat pad to infant/toddler feeding booster
seat as shown. Pull waist straps through openings
in seat pad.
12
Pull shoulder straps and crotch strap through
openings in seat pad.
13 Wrap seat pad over the top of the infant/toddler
feeding booster seat.
14 Make sure recline handle is sticking out the hole in
the seat pad.
15 Secure seat pad with hooks as shown.
16
Secure seat pad with hooks at the front of seat as
shown.
17 Fasten snaps as shown.
Body Support
18 Place body support on top of the seat pad.
19 Pull waist straps through openings in body
support.
20
Pull shoulder straps and crotch strap through
openings in body support.
Attaching Infant/Toddler Feeding
Booster Seat to Highchair
21 Fold and store straps in compartment on bottom
of infant/toddler feeding booster seat as shown.
22 Close compartment door.
MAKE SURE the compartment door is closed
before attaching infant/toddler booster seat back
onto the highchair frame.
23 Place infant/toddler feeding booster seat on
highchair.
NOTE: Be sure that guides on sides of infant/
toddler feeding booster seat go into channels on
highchair arms as shown.
Make sure the clear compartment holding the
straps under the seat is closed before attaching
seat to highchair frame.
24 Check infant/toddler feeding booster seat is
latched into place by pulling up on it.
25 To remove infant/toddler feeding booster seat,
push in buttons on side of seat and pull up.
Attaching Basket (certain models only)
26 Collect fabric basket for attachment.
NOTE: Be sure that the widest of the short sides
faces front. Mesh should be shown on sides only.
27 Attach basket to legs as shown. Snap
basket button tabs around legs as shown to
secure to chair.
Tray
28 To attach tray, squeeze both side handles on
bottom of tray and place on highchair or squeeze
button and slide on.
29
To remove tray, squeeze both side handles on
bottom of tray and lift up or squeeze button and
slide off.
