EBARA SP FC 1,5T-2 Instructions Pour L'installation Et La Maintenance page 43

16 A three-phase EMC filter
XL1
N.B. Only used on panels up to 7.5 kW.
Fuses protecting the line and the inverter.
Their intervention inhibits the operation of the electropump fed by the inverter but not that of the
system.Switch off power before performing maintenance.
16 A gG
10x38
SP FC 1,5T-2
FU1
2 SP EFC 1,5T-2
3 SP EFC 1,5T-2
SP FC 2,2T-2
2 SP EFC 2,2T-2
3 SP EFC 2,2T-2
Fuses protecting the line motor 2 and 3 direct powered from the net.
The intervention inhibits the functioning of the electric pump, but not of the plant.
Switch off power before performing maintenance.
10 A aM
10x38
FU2
SP FC 1,5T-2
FU3
2 SP EFC 1,5T-2
FU6
3 SP EFC 1,5T-2
SP FC 2,2T-2
2 SP EFC 2,2T-2
3 SP EFC 2,2T-2
50 A aM
14x58
SP FC 18,5SD-2
2 SP EFC 18,5SD-2
3 SP EFC 18,5SD-2
Fuse protecting the primary circuit of the transformer and of the board KL3
against short circuits, 1 A rapid 6.3x31.
FU4
Its intervention inhibits the operation of the system.
Switch off power before performing maintenance.
Fuse protecting the secondary circuit of the transformer and of the board
KL3 against short circuits, 4 A delayed 5x20.
FU5
Its intervention inhibits the operation of the system.
Switch off power before performing maintenance.
Fuse protecting the primary circuit of the transformer and of the board against short circuits 2 A aM 10x38
FU7 Its intervention inhibits the operation of the system.
Switch off power before performing maintenance.
Fuse protecting the secondary circuit of the transformer and of the board against short circuits 4 A retarded 5x20, 8
A retarded 5X20 for boards SP FC 30SD-2 – 2 SP EFC 30SD-2 – 3 SP EFC 30SD-2.
FU8
Its intervention inhibits the operation of the system.
Switch off power before performing maintenance.
Supply line insulating switch with door locking handle which may be padlocked.
QS1
XLM1 INDUCTOR COD. 50.003.08.0. TO BE USED FOR MOTOR CABLES UP TO A 50 MT TO
REACTANCE TO INSTALL OUTSIDE THE PANEL AND TO COMPLY WITH THE 61000-3-2
STANDARD.
XLL1
ENGLISH
20 A gG
25 A gG
10x38
10x38
SP FC 3T-2 SP FC 5,5T-2
2 SP EFC 3T-2 2 SP EFC 5,5T-2
3 SP EFC 3T-2 3 SP EFC 5,5T-2
SP FC 4T-2
2 SP EFC 4T-2
3 SP EFC 4T-2
12 A aM
16 A aM
10x38
SP FC 3T-2 SP FC 5,5T-2
2 SP EFC 3T-2 2 SP EFC 5,5T-2
3 SP EFC 3T-2 3 SP EFC 5,5T-2
SP FC 4T-2
2 SP EFC 4T-2
3 SP EFC 4T-2
63 A aM 80 A aM
NH00
SP FC 22SD-2 SP FC 30SD-2
2 SP EFC 22SD-2 2 SP EFC 30SD-2
3 SP EFC 22SD-2 3 SP EFC 30SD-2
10 A → cod. 191X9026
16 A → cod. 191X9027
25 A → cod. 191X9028
32 A gG
10x38
SP FC 7,5T-2
2 SP EFC 7,5T-2
3 SP EFC 7,5T-2
20 A aM
10x38 10x38
SP FC 7,5T-2
2 SP EFC 7,5T-2
3 SP EFC 7,5T-2
NH 00
43
63 A Gg
NH00
SP FC 11SD-2
2 SP EFC 11SD-2 2 SP EFC 30SD-2
3 SP EFC 11SD-2 3 SP EFC 30SD-2
SP FC 15SD-2
2 SP EFC 15SD-2
3 SP EFC 15SD-2
SP FC 18,5SD-2
2 SP EFC 18,5SD-2
3 SP EFC 18,5SD-2
SP FC 22SD-2
2 SP EFC 22SD-2
3 SP EFC 22SD-2
25 A aM
14x51
SP FC 11SD-2
2 SP EFC 11SD-2 2 SP EFC 15SD-2
3 SP EFC 11SD-2 3 SP EFC 15SD-2
32 A → cod. 191X9029
38, 44, 61 A → cod. 191X9030
80 A Gg
NH 00
SP FC 30SD-2
40 A aM
14x58
SP FC 15SD-2
