5

System Operation

5.1

Front of Pump

(1) (2) (3) (4) (5) (6)
(17)
(16)
(15)(14) (13) (12) (11)
Please familiarize yourself with the layout of the individual elements on the front
of the pump.
5.2

Rear of Pump

(1) (2) (3)
(11)
(12)
(10) (9)
Please familiarize yourself with the layout of the individual elements at the rear
of the pump.
CAUTION!
Any devices to be connected via the interface have to comply with EN 60950.
(7)
(10) (8)
(9)
(4)
(5)
(12)
(8) (7) (6)
System Operation
Fig. 5-1 Front of Pump
Pump display
(1)
Intrauterine pressure display
(2)
Fluid deficit limit
(3)
Deficit meter
(4)
Deficit display
(5)
(6) Inflow tube holder
Roller wheel
(7)
Pressure sensor
(8)
Reset deficit button (Zero)
(9)
Decrease deficit limit
(10)
Increase deficit limit
(11)
Decrease intrauterine pressure set-
(12)
ting
(13) Increase intrauterine pressure set-
ting
Intrauterine pressure setting dis-
(14)
play
ON/OFF switch
(15)
Pause/Resume button
(16)
Prime button
(17)
Figure 5-2 Rear of Pump
Low vacuum port (white)
(1)
Product ID label
(2)
(3) Device performance data
Adjustment dial for high vacuum
(4)
High vacuum port (green)
(5)
Fuse holder(s)
(6)
Power cord connection
(7)
MyoSure® Control Unit Power Con-
(8)
nection
Potential equalization connector
(9)
(10) Service interface
Scale connection
(11)
Exhaust ports
(12)
