Preparation

To start squeezing you must follow the steps below:
Step 1 Unpack your juicer and place it on a surface as horizontal as possible.
Step 2 Ensure that the mains power falls within the margins indicated on the Iden-
tiication Label of the machine which you will ind both on the cover page of this
manual as well as on the machine itself.
Step 3 Place the peel buckets as indicated in Fig. 1 and 4.
Paso 4 Make sure that the juice container and its ilter are placed correctly and that the
cover is closed and secured by the catch.
ZUMEX ESSENTIAL BASIC. Before starting the unit, place the orange feeding tube in
the position shown on Fig. 2. Use the 4 mm Allen key supplied with the machine
If you have acquired a juicer with a podium, you must place the juicer on the podium,
screw it as indicated in the instruction supplied on the podium. Don't forget to secure
the front wheels. Then place the hopper and the peel buckets with an open base
which you will ind inside the stand (Fig. 5).
REMEMBER:
65 and 78 mm recommended)

Operation

Essential Basic: Place a glass / jug under the juice outlet and press the green button
(Fig. 3). The machine will start to operate when you press the button. To stop the
juicer, press the red button.
Essential Pro and Versatile Pro: Once the previous steps have been followed, connect the
connecting plug to a socket base itted with a standardized ground. And press the sleeve
button to start up the machine.
When you turn on the machine for the irst time after purchase, a message will appear:
"Select language" in order to select the operating language of the machine.
Usage Instructions
42
Use fruit which does not exceed 81 mm in diameter. (Between
English
