Extraction arm length Note
2 m, 3 m, 4 m
5 m, 6 m, 7 m
7 m, 8 m
9 m, 10 m
B [mm]
898
3. Drill the four drill holes according to the table. Use a spirit level for
alignment and make sure that the profiles of the product (item 1) are
exactly aligned with the wall mount brackets (item 3).
1502518-00
Fig. 31: Mounting height + drill hole dimensions
With cantilever arm 2 + 3 m
With cantilever arm 4 m
With cantilever arm 6 m
Tab. 21: Mounting height
C [mm]
715
Tab. 22: Drill hole dimensions
D [mm]
Ø 13
- 75 -
EN
A [mm]
2,400
3,000
3,250
3,490
