Dalla Corte Evolution Notice Pour L'utilisateur page 27

Machine and control panel overview
Pic.2
5
6
8
12
1 Main switch
2 Drip tray
3 Drip tray grill
4 Steam wand
5 Steam valve
6 Hot water spigot Led1 Button
7 Water pressure manometer
13
9 10 11
8 Boiler pressure manometer
9 Dispensing group head
10 One-cup filter holder
11 Two-cup filter holder
12 Adjustable foot
13 Hot water dispensing buttons
