The display has a header line at the top and a footer line at the bottom. The header
displays the title of the current menu. The footer line displays the time and the date,
the data logger status and the battery status. The menu selection window is in the
middle of the display between the header and the footer.
The menu selection window displays information in two general formats. In the fi rst
format only menu selections are displayed. Up to 4 lines of menu selections may be
displayed. If more selections are available they can be viewed by pressing the arrow
buttons
window. Think of the menu selections as a vertical list in the display that moves up
or down each time an arrow button
2020t/i are looping menus. The top and bottom menu choices are connected in a
loop. Scrolling down past the bottom of the menu will lead to the top of the menu.
Scrolling up past the top of the menu will lead to the bottom of the menu.
Main Selection Window
A light colored bar will indicate the menu choice. As the menu is scrolled through,
the light colored bar will highlight diff erent menu choices. Pressing the
will select the menu choice that is indicated by the light colored bar.
In the second format the menu choice window takes advantage of the graphical
capabilities of the display. Large format graphic information, such as test results or
error messages or the LaMotte logo is displayed. The top two lines of the display are
used to display information in a large, easy to read format. The menus work in the
same way as previously described but only two lines of the menu are visible at the
bottom of the display.
Message or Result Window
Main Selection Window
to scroll the other menu selections into the menu selection
Header
First Choice
Second Choice
Third Choice
Another
Footer 12:00:00
And Another
And So On
Header
Result or Message
Another
And Another
Footer 12:00:00
And So On
Last Choice
is pressed. Some menus in the
Menu Title
001/500
Title
Menu
001/500
41
button
ENTER
