Hose system
1
RV 10.5001 Water valve
(
Optional)
6
Silicon hose (inner dia. 6 mm)
for water
10
10
RV 10.2_20
RV 10.1_10
Note: Observe "Drawings for connecting the hose system" on page 232.
RV 10 control operation
• Fit RV 10.4002 vacuum, in the bracket provided for this purpose
and connect the vacuum hose to the valve.
Connect RV 10.4002
3
2
RV 10.4002 Vacuum valve
for silicone hose
pos. 5, 6 & 7
7
Silicon hose (inner dia. 7 mm)
for water
10 10
RV 10.3_30
RV 10 auto operation
• No additional valve is required for vacuum normal operation
• Connect the pump controller cable to RV 10 control.
Note: When connecting the
pump controller cable, make
sure that the snap-and-lock
plug has been inserted into the
stop position inside the pump
controller cable connection.
Connect RV 10 temperature sensor (dT)
• Connect the temperature sensor to the lower socket (dT). Al-
Note: When connecting the
temperature sensor, make sure
that the snap-and-lock plug has
been inserted into the stop posi-
tion inside the temperature sen-
sor connection.
4
Hose clamp Hose clamp Silicon hose (inner dia. 5 mm)
for vacuum hose
pos. 8
8 9
Vacuum hose
10
RV 10.4_40 RV 10.5_50
with a speed-vacuum control pump. Connect the pump's vacu-
um inlet directly to the RV 10 pump hose connection.
ways check for correct direction of the arrow.
5
for water
Connector
for water valve
10
RV 10.6_60




