EXHAUST CONNECTION
18
WARNING - TO REDUCE THE RISK OF
FIRE OR PERSONAL INJURY:
• This dryer must be exhausted to the outdoors.
• Use only metal duct.
• Do not terminate exhaust in a chimney, any gas vent,
under an enclosed floor (crawl space), or into an
attic. The accumulated lint could create a fire hazard.
• Provide an access for inspection and cleaning of the
exhaust system, especially at turns. Inspect and clean
at least once a year.
• Never terminate the exhaust into a common duct with
a kitchen exhaust. A combination of lint and grease
could create a fire hazard.
• Do not obstruct incoming or exhausted air.
WE RECOMMEND THAT YOU INSTALL YOUR DRYER
BEFORE YOUR WASHER. THIS WILL PERMIT DIRECT
ACCESS FOR EASIER EXHAUST CONNECTION.
THIS DRYER COMES READY FOR REAR EXHAUSTING. IF
SPACE IS LIMITED, USE THE INSTRUCTIONS IN SECTION
23 TO EXHAUST DIRECTLY FROM THE LEFT SIDE OR
BOTTOM OF THE CABINET.
STANDARD REAR EXHAUST
WE STRONGLY RECOMMEND THE USE OF
RIGID METAL EXHAUST DUCT. IF USING
FLEXIBLE METAL DUCT, CUT IT TO THE
PROPER LENGTH AND AVOID BUNCHING
OF THE DUCT BEHIND THE DRYER.
FOR STRAIGHT
LINE INSTALLATION,
CONNECT THE
DRYER EXHAUST
TO THE WALL USING
DUCT TAPE.
ELBOW HIGHLY
RECOMMENDED
NOTE: ELBOWS WILL PREVENT DUCT KINKING
AND COLLAPSING.
LEVELING DRYER
19
LEVEL
FRONT-TO-BACK.
4 LEVELING
LEGS
STAND THE DRYER UPRIGHT NEAR THE FINAL
LOCATION AND ADJUST THE 4 LEVELING LEGS TO
MATCH THE HEIGHT OF YOUR WASHER. ADJUST
THE 2 ANTI-TIP LEGS TO CONTACT THE FLOOR.
16
ELBOW HIGHLY
RECOMMENDED
RECOMMENDED
CONFIGURATION
TO MINIMIZE
EXHAUST
BLOCKAGE.
LEVEL
SIDE-TO-SIDE.
2 ANTI-TIP LEGS
