GE UPSE810 Manuel D'utilisation page 11

CHANGING DIRECTION OF
10
DOOR OPENING
1. Open the door and remove the filler plugs opposite the
hinges. With the door completely open, remove the
bottom screws from each hinge on the dryer face. Insert
these screws about half way into the TOP holes, for each
hinge on the opposite side (where you removed the filler
plugs). Apply firm pressure to get the screw started.
2. Loosen the top screws from each hinge on the dryer
face half way. With one hand holding the top of the door
and the other hand holding the bottom, remove the door
from the dryer by lifting it UP and OUT.
3. Rotate the door 180º. Insert the door on the opposite
side of the opening by moving the door IN and DOWN
until the top hinge and the bottom hinge are resting on
the top screws inserted in step 1.
4. Remove the remaining screws from the side of the
opening from which the door was removed. With these
screws secure each hinge at the bottom. Tighten the two
top screws on each hinge. Reinsert the plastic plugs on
the side from which the door was removed.
REMOVE THE
BOTTOM SCREW
FROM EACH HINGE
ON THE DRYER
FACE.
MOVE THE DOOR IN AND
DOWN UNTIL THE TOP
HINGE AND THE BOTTOM
HINGE ARE RESTING ON
THE TOP SCREWS
INSERTED IN STEP 1.
SERVICING
11
WARNING - LABEL ALL WIRES PRIOR TO
DISCONNECTING WHEN SERVICING
CONTROLS. WIRING ERRORS CAN CAUSE
IMPROPER AND DANGEROUS OPERATION
AFTER SERVICING/INSTALLATION.
For servicing phone numbers for replacement parts, and
other information, refer to Owner's Manual or visit our
Web site.
LOOSEN THE TOP
SCREWS FROM
EACH HINGE ON
THE DRYER FACE
HALF WAY.
SECURE EACH HINGE
AT THE BOTTOM AND
TIGHTEN THE TWO TOP
SCREWS OF EACH HINGE.
11
