7.9 Using the laser (Fig. 43 – 45 / Item 21)
To switch on: Move the laser ON/OFF switch (42)
into the "I" position to switch on the laser (21). A laser
line is projected on to the workpiece you wish to
machine, providing an exact guide for the cut.
To switch off: Move the laser ON/OFF switch (42)
into the "0" position.
Adjusting the laser: Undoing the screws (41)
slightly allows the laser to be adjusted if necessary.
Tighten the screws again after you have completed
the adjustment work. Important. Never look directly
into the LED light!
Replacing the battery: Ensure that laser (21) is
switched off. Remove the battery compartment cover
(43). Remove the spent batteries and replace them
with new ones (2 x 1.5 V type R02, LR 03 Micro,
AAA). Check that the battery terminals are positioned
correctly. Close the battery compartment again.
7.10 Transport (Fig. 1 – 3)
Tighten the locking grip (14) to lock the turntable
(17).
Press the release lever (3), push the machine
head (4) to the rear and lock it with the locking
bolt (27). The saw is now locked in its lower
position.
Secure the drag function of the saw in its rear
position using the fixing screw for the drag guide
(25).
Carry the machine using the fixed saw bench (18)
or, if the saw is mounted on the base frame, using
the appropriate trough handles on the base
frame.
Follow the instructions set out in point 6.2 to erect
the machine again.
7.11 Battery disposal
Recycle the packaging. Ensure that you sort the
materials for recycling. Do not dispose of batteries in
household waste. All consumers have a duty to
dispose of batteries properly at the appropriate
collection points. Send your spent batteries to iSC
GmbH, Eschenstrasse 6 in D-94405 Landau. You can
then be sure that the equipment will be correctly
disposed of by the manufacturer.

8. Replacing the power cable

If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
12.01.2009 16:18 Uhr Seite 27
9. Cleaning, maintenance and ordering
of spare parts
Always pull out the mains power plug before starting
any cleaning work.
9.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
We recommend that you clean the device
immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts
of the equipment. Ensure that no water can seep
into the device.
9.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important! The carbon brushes should not be rep
laced by anyone but a qualified electrician.
9.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
9.4 Ordering replacement parts
Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info

10. Disposal and recycling

The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material
and can therefore be reused or can be returned to
the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic.
Defective components must be disposed of as
special waste. Ask your dealer or your local council.
