BLADE ADJUSTMENT (Fig. 6)
adjusted taking a lot of attention. After the blade change and after some working hours it is necessary the adjustment the blade-holders
(1) using the screws (2) and the corresponding lock nuts (3).
Before every registration it is very important to clean the bar from the dirty in order to avoid wrong adjustments..
The blade-holders (1) have to be adjusted one per one , so go on adjusting the first blade-holder , then the second, then the third, etc..
For the blade adjustment , we suggest you to operate on the blade-holders (1) .
IMPORTANT : for the control for each blade adjustment : you have first to disassemble the cover (4): unscrew the nut (6), remove the
washer (5) turn it upwards and remove it from the pin (A); then slowly make the pulley to turn by hand (7) and verify the blades to freely
turn. Re-assemble the cover .
CUTTER BAR SERVICING :
particular for the surfaces which are in contact between the slide and the blade sections is absolutely necessary every use. If the machine
is not used for long periods, please protect the cutter and the blade using anti-corrosive and anti-oxidizing substances.
BLADE PROTECTION (Fig. 7)
happen with the blade protection (1) connected. For a better safety we recommend to protect the blade even during the transport, the
servicing and the garaging. In case you, see damaged blade protections they cannot guarantee a safe covering and have to be changed.
HOW TO MAKE THE BLADE REPLACEMENT (Fig. 8 - 8/A):
always be carried out wearing protective gloves.
Procedure for replacing blades:
- Remove the protective cover (1): unscrew the nut (3), remove the washer (2), turn it upwards and remove it from the pin (A).
- Remove the drive belt (4) from the pulley (B).
- Unscrew the screws (5) and the nuts (6), remove (lift) the bar movement (8) from the cutter bar body (7).
- Unscrew the screws (10) and the nuts (11), remove the washers (12) and remove the bar attachment (9) from the cutter bar body (7).
- Remove the upper blade movement plate (13), unscrewing the screws (14) and removing the washers (15)
- Using a pin tool inserted in the hole (C), remove the upper blade (16).
- Turn over the cutter bar body (7)
- Remove the lower blade movement plate (17), unscrewing the screws (18) and removing the washers (19).
- Using a pin tool inserted in the hole (D), remove the lower blade (20).
After 2 or 3 sharpenings it is recommended to replace the blades.
To reassemble the blades on the bar, repeat the above operations in reverse.
ATTENTION: To fix the upper (13) and lower (17) blade movement plates, apply some thread locking on the screws (14) and (18). We
recommend you to lubricate the contact surfaces of the blades (16) and (20) before reassembling them.
CUTTER BLADES SHARPENING (Fig.9)
RECOMMEND YOU NOT TO OVERCOME 15 HOURS WORK. For this reason the blade should be removed and cleaned . Please verify
if the teeth and the the two blades are not deformed then you can proceed with the sharpening. In general you could use a hand grinder
with about 15000-20000 turns/min. with a sharpening drill / cup shaped grinding point diameter of 25 mm and lenght of about. 35 mm.
Cutter bar teeth need a cutting angle 35°-40°.
Please pay attention not to overheat them too much or they would loose their strenght due to the thermal treatment. The toe of tooth
SHOULD NOT be rounded ( please look at the picture).

TECHNICAL DATA:

mowing width = 1020 mm - machine length with cutter bar = 1680 mm. – cut frequency of the cutter bar =
1000/1'. Net Weight Complete Bar 23 Kg. Gross Weight Complete Bar = 26 Kg. - Package size for Complete Bar = 112x38xH22 (internal
measures in cm.) - Net weight Only bar and no bar movement Bar = 12 Kg - Gross weight Bar and bar movement only no connection Bar
= 13.5 Kg - Packaging dimensions for bar movement only and no connection Bar = 54x33xH30 (internal dimensions in cm.)
DE
ACHTUNG: Dieser Gebrauchshinweis versteht sich als Zusatz zu den in der Bedienungs- und Wartungsanleitung der Maschine
aufgeführten Vorschriften, die beachtet und gelesen werden müssen. Der Balkenmäher ist ausschließlich für den professionellen
Gebrauch und zum Gebrauch auf Privatgrundstücken geeignet.

SICHERHEITSVORSCHRIFTEN

und Armverletzungen dar. Dementsprechend muss man bei den nachstehend beschriebenen Vorgängen wie Auswechseln und Schleifen
der Messer besondere Vorsicht walten lassen. Vor dem Einschalten des Geräts darauf achten, dass sich außer dem Bediener keine
weiteren Personen oder Tiere im näheren Umfeld aufhalten.
MONTAGE DES MÄHANTRIEBES AM BALKENMÄHER (ABB.1):
entnommen wurden, bitte wie folgt vorgehen:
- Die Schrauben (2) und Muttern (3) von der Anbauplatte des Mähbalkens (1) lösen,
- Den Mähantrieb (4) auf den Mähbalken (1) setzen, unter Beachtung, dass die Bohrungen A) des Mähantriebes (4), mit den Bohrungen
(B) des Mähbalkens (1) übereinstimmen.
- Die Verbindung mit den zuvor entfernten Schrauben (2) und Muttern (3), herstellen.
MONTAGE DES MÄHBALKENS (ABB. 2 – 2/A)
Maschine (1) in den Schnellanschluss (2) einführen. Dann den Riemen (3) zuerst auf die Riemenscheibe (4) an der Maschine, dann auf
die Riemenscheibe (5) des Mähbalkens aufziehen. Dann den Zapfen (1) bis zum Anschlag bringen. Rückholfedern (6) in die Bohrungen
The cutter bar is considered among the agricultural equipment the most stressed one and should be
the cutter bar needs to have a good and frequent servicing. The washing and the clearing of the blade, in
The operations for the assembly and disassembly of the cutter bar to the machine should always
Considering the work frequency , the blade should be sharpened from time to time. WE
Die scharfen Bauteile des Mähbalkens stellen bei Unachtsamkeit ein erhebliches Risiko für Fuß-
The disassembly and assembly of the complete blades must
Ü
berseTzung der originalen
Nachdem die Verpackung geöffnet und alle Bauteile
Bei ausgeschalteter und horizontal abgestellter Maschine den Zapfen der
