DKN R-400 Instructions D'utilisation page 44

No. Description
G-5 SCREW
G-6 SCREW
G-7 FLAT WASHER
G-8 FLAT WASHER
G-9 NYLON NUT
G-10 SPRING FOR IDLER WHEEL
H SPRING BOX
H-1 SPRING
H-2 FLYWHEEL AXLE
H-3 SCREW
H-4 FIXING PIN
H-5 COVER OF SPRING BOX
H-6 SCREW
H-7 BUSHING
H-8 NUT
H-9 FIXING PIN
H-10 NUT
H-11 BEARING
H-12 IRON RING(1)
H-13 SCREW
H-14 IRON RING(2)
H-15 BEARNG
H-16 ONE WAY BEARING
H-17 PULLEY
H-18 BEARING
H-19 FLAT WASHER
H-20 BEARING
I-1 SCREW
I-2 FLAT WASHER
Q'ty No. Description
1 I-3 SCREW
1 I-4 SCREW
1 J PEDAL HOLDER
1 J-1 STOPPER
1 J-2 SCREW
1 J-3 PEDAL
1 J-4 PAD OF PEDAL
1 J-5 PEDAL STRAP
1 K ROLLING SLIDER
1 K-1 SADDLE
1 K-2 ROLLER
1 K-3 NLYON NUT
4 L MAGNETIC SET
1 L-1 FLAT WASHER
3 L-2 SPRING WASHER
2 L-3 SCREW
2 L-4 SCREW
1 L-5 FLAT WASHER
1 L-6 SLEEVE
1 L-7 NYLON NUT
1 L-8 FLAT WASHER
1 L-9 SLEEVE
1 L-10 CHAIN
1 L-11 NYLON NUT
1 L-12 SCREW FOR GEAR BOX
1 L-13 GEAR BOX
1 L-14 SMALL SPRING
8 M-L LEFT SILDER
8 M-R RIGHT SLIDER
Q'ty No. Description
8 M-1 SCREW
4 M-2 NYLON NUT
1 M-3 STOPPER FOR SILDER
1 N REAR STABILIZER
2 N-1 ADJUSTING CAP
2 N-2 SCREW
2 N-3 TRANSOPORTATION BAR
2 N-4 FLAT WASHER
1 N-5 SCREW
1 N-6 REAR COVER FOR SLIDER
4 O AC ADAPTOR
4
1
2
2
2
1
1
1
1
1
1
1
2
1
1
1
1
1
Q'ty
2
2
1
1
2
2
1
4
4
1
1
