Evolution R255 SMS Notice Originale page 13

www.evolutionpowertools.com
24
37
25
33 34
21. Miter Angle Scale
22. Dust Port Adapter
23. Front Clamp
24. On / Off Trigger Switch
25. Front Cable Guide Clamp
26. Dust Extraction Port
27. Cable
28. Cutting Head Locking Pin
29. Rear Sliding Carriage
30. Rear Cable Guide Clamp
36
35
31. Bevel Lock Handle
32. 33.9˚ Bevel Pin
33. M4 Self Tapping Cap Screw X1
34. M4 Socket Head Screw X4
35. Cable Grip Component
(Fitted To The Cable Guide Clamp)
36. Anti-Vibration Spring
(Fitted To Item '4' - The Slide Locking Screw)
37. Laser Guide On / Off Switch
13
Pictured: R255SMS
26
27
28
29
30
31
32
