MACHINE OVERVIEW

1
2
3
4
5
6
7
8
9
22
(Sold Separately)
1. Cutting Handle
2. Dust Bag
3. Slide Locking Screw
4. Depth Gauge
5. 3 Pc Hold Down Clamp
6. Sliding Fence
7. Machine Table Extensions
8. Mounting Hole (X4)
9. Front Clamp Holes
10. Blade Rotation Indication Arrow
23
11. Upper Blade Guard
12. Cutting Head
13. Blade
14. Lower Blade Guard
15. Laser Guide
16. Table Top
17. Rotary Table
18. Table Insert
19. Miter Handle Locking Knob
20. Positive Stop Locking Lever
