ARF868 Radio Modems - User guide version V1.6
1.10. Protection of remote aerial modems against overloads
It is sometimes necessary to protect the product against lightning. When the product is positioned high up it can potentially be struck by
lightning which results in irreversible damage to the product. All lightning arrester systems can be installed between the aerial and the ARF868
modem (products with remote aerials). It is important to follow the manufacturer's recommendations. The diagram below shows an example of
a lightning arrester installation.
No Description
1 TNC connector of ARF868 modem
2 Mounting nut
3 Tooth lock washer
4 12-10 AWG wire
(must be earthed)
5 Round terminal
6 O ring seal
7 Lightning arrestor
8 Male-Male TNC adapter
9 Aerial
2. Electrical and radio specifications
2.1. Maximum values
Parameters
Voltage
Storage temperatures

2.2. General specifications

Parameters
Voltage range
TX consumption
RX consumption
Operating temperatures
Min Typ
4.5 12
-40 20
Min Typ
4.5V 12 or 24V
600 (@4.5V)
300 (@4.5V)
170 (@4.5V)
130 (@4.5V)
40 (@4.5V)
-30
Reference
delivered with product
delivered with product
RS : 613-9429
delivered with product
RS : 111-658
RS : 193-7953
Max Unit
36
+85 °C
Max Unit
36V
95 (@36V) mA
65 (@36V) mA
35 (@36V) mA
30 (@36V) mA
7 (@36V) mA
+70 °C
Conditions
V
Conditions
V
@27dBm
@20dBm
@14dBm
@10dBm
Page 12 of 25
