REMOVING THE ATTACHMENT FROM THE POWER HEAD
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Press the shaft-release button and, with the button pressed, pull or twist the
hedge trimmer shaft out of the coupler to separate it from the power head.
MOUNTING THE TIP PROTECTOR
(Available separately)
1. Use a 3mm hex wrench (not
included) to remove the short bolt,
plain washer, bushing and nut at the
end of the blade (Fig. 7). Save the
plain washer, bushing and nut for
reassembly.
2. Align the tip protector with the bulge
on the blade and mount it into place.
Secure it with the new long bolt and
nut as well as the saved washer,
bushing and nut (Fig. 8).

OPERATION

DANGER:
lines, electric cords, or other electric
sources. If the blades jam on any electrical cord or line, DO NOT TOUCH THE BLADE
OR THE ALUMINUM POLE! THEY CAN BECOME ELECTRICALLY LIVE AND MAY BE VERY
DANGEROUS. Continue to hold the hedge trimmer by the insulated rear handle or lay
it down and away from you in a safe manner. Disconnect the electrical service to the
damaged line or cord before attempting to free the blade from the line or cord. Contact
with the blade, other conductive parts of the hedge trimmer, or live electric cords or
lines will result in death by electrocution or serious injury.
20
HEDGE TRIMMER ATTACHMENT—HTA2000
Never cut near power
7
8
Bulge on
the blade
Nut
Bushing
Plain Washer
Short Bolt
Nut
Tip Protector
Nut
Bushing
Plain Washer
Long Bolt
